10
S T E P
3
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step unless otherwise noted.
A. Connect both Straight Hangers (E) to Main Body (A) and Bar Catch (F) by
using:
Two 13 (M10x140 hex head bolt)
Four 16 (M10x135 hex head bolt)
Twelve 15 (M10 washer)
Six 14 (M10 nylon nut)
B. Connect Top (G) to Main Body (A) using:
Two 10 (M8x20 hex head bolt)
Two 12 (M8 washer)
C. Make sure the unit is on a completely level surface.
Fully tighten all hardware at this time.
D. Enjoy your workout!
