Body Solid VDRA30 - Hardware Information; Hardware List and Quantities

12
H a r d w a r e L i s t
Part numbers are required when ordering parts.
Part# Qty Description
A 1 Main Body
B 2 Leg
C 1 Bar Shelf
D 2 Bent Hangers
E 2 Straight Hangers
F 1 Bar Catch
G 1 Top
8 4 Foot Cap
9 1 Rubber Pad 240mm x 130mm
10 12 Hex Head Bolt M8x20
11 4 Hex Head Bolt M8x40
12 16 Washer M8
13 2 Hex Head Bolt M10x140
14 6 Nylon Nut M10
15 12 Washer M10
16 4 Hex Head Bolt M10x135
17 1 Rubber Pad 250mm x 95mm
