BODYMAX MB40 - 8.2 Parts List

1 Front stabilizer 1 31 Seat post 1
2 Hexagon nut M8*H5.5*S14 5 32 End cap PT50*25*16 2
3 Foot pad Φ52*43*M8 5 33 Washer d10*Φ30*2.5 1
4 End cap PT70*30*20 4 34 Knob M10*Φ58*32 1
5 Screw M6*12*S5 2 35 Cover 99.3*83.5*24.7 1
6 Bearing 608ZZ 4 36 Bushing
PT70*30*PT60*20*L145*10
1
7 Transport wheel Φ71*Φ19*24 2 37 Crank plug Φ25*7 2
8 Screw Φ7.8*30*M6*15*S5 2 38 Hexagon nut M10*1.25*H7.5*S14 2
9 Screw M8*20*S6 4 39L/R Crank 2
10 Spring washer d8 7 40L/R Pedal 2
11 Washer d8*Φ16*1.5 7 41 Screw ST4.2*16*Φ8 6
12 Rear stabilizer 1 42 Screw ST4.2*19*Φ8 10
13 Knob M16*1.5*Φ27 2 43L/R Belt Cover 2
14 Bushing PT80*40*PT70*30*L130 1 44 C Clip d17 1
15 Brake block 68*75*39.2 1 45 Bearing 6203-2RS 2
16 Screw M5*7*Φ10 6 46 Bushing Φ22*Φ17.1*5.5 1
17 Brake cable Φ1.5*305*42 1 47 Magnet Φ15*7 1
18 Bolt M6*10*H26*S5 1 48 Belt Wheel Φ220*20*Φ17.1*4-
Φ6*Φ60-6PJ
1
19 Brake handle 1 49 Middle Axle Φ17*172*4-Φ6.1*Φ60 1
20 WasherΦ8.5*Φ23.5*3 1 50 Bolt M6*16*S10 6
21 SpringΦ1.2*Φ11*21*N7 1 51 Belt 1
22 Cable base t3*25*23 1 52 Tension knob 1
23 Nylon nut M6*H6*S10 8 53 Spring washer d6 2
24 Hexagon bolt M6*10*S10 1 54 Washer d6*φ12*1.2 2
25 Washer d6*Φ16*1.5 1 55 RING-SHIELD d12 2
26 Bearing 6001-2RS 4 56 Magnet 40*25*10 7
27 idle pulleyФ39*Ф34*24 1 57 Magnet Holder 45.5*130*10.5 2
28 Wave washer d12*Φ15.5*0.3 1 58 Magnetic plate 1
29 Seat 1 59 Magnetic plate shaft
φ12*53.5*47.4*M6
1
30 Seat slider 1 60 Screw ST3*10*Φ5.6 9
MB40
25
8.2 Parts List
No. Name Qty.
No.
Name Qty.
