Part List
Part no. Description Drawing no. Material Specification Q'ty
1 Main frame 737RB-3-1000-J6 1
2 Front stabilizer 70501-6-2101-J0 Q195 D76x1.5Tx480L 1
3 Bottle holder 70402-6-2074-00 PVC 120*87*3T 1
4 Bolt 52605-5-0015-F0 10# M5*0.8*15L 2
5 Handlebar set 80201-3-2400-J5 1
6 Rear stabilizer 70501-6-2107-J1 Q195 D76x1.5Tx480L 1
7 Seat post 711RB-3-2200-J1 1
8 Computer 737RK-6-2501-B0 SM-1730-31 1
9L Left rolling foot cap 554C0-H-0076-B11 PP D76*120L 1
9R Right rolling foot cap 554C0-R-0076-B11 PP D76*120L 1
10 Handlebar post tube 737RB-3-2000-J0 1
11 Spring washer 55108-2-1520-FA 70# D15.4xD8.2x2T 14
12 domed nut 55208-6-2015-FA 35# M8x1.25x15L 6
13 Bolt 50308-5-0020-F0 35# M8x1.25x20L 8
14 Flywheel set 737RF-2-3100-00 1
15 Bolt 50308-5-0040-F3 35# M8*1.25*40 8
16 Screw cover 81502-6-2779-B0 PE D26*11L 2
17 Plastic washer 55110-1-2404-BF NL66 D10*D24*0.4T 2
18 Seat 80700-6-1146-B10 PVC 348*270*52 1
19 Bolt 50310-5-0035-C3 35# M10*35L 1
20L&R Pedal set 58029-6-1032-B0 JD-22A 9/16"tooth 1
21 Flat washer 55108-1-3020-NA Q235A D30*D8.5*2.0T 1
22 Screw 50904-2-0020-D0 10# ST4*1.4L*20L 2
23 Anti-slip nut 18600-6-3175-N1 Q235A 3/8"-26UNFx6.5T 2
24 Fixed bracket for magnet 706E2-3-3200-N0 1
25 Backrest 80700-6-1145-B10 PVC 410*340*57 1
26 Tension cable 719M0-6-2602-02 D1.5*130L, 1
27 Spring 58003-6-1054-N0 72A D1.0*55L 1
28 Bolt 50106-5-0065-N0 35# M6*65L 1
29 Nut 55206-2-2006-NA Q235A M6*1*6T 1
30 Bolt 50308-5-0095-F4 35# M8*1.25*95L 4
31 Curved washer 55108-3-2215-FA Q235A D22xD8.5x1.5T 10
32 Power cord 702A2-6-2596-00 400L 1
33 Sensor cable 737RB-6-2576-00 400L 1
34 Waved washer 55117-5-2203-DA 65Mn D22*D17*0.3T 2
35 C-ring 55517-1-0010-00 65Mn S-17(1T) 1
