7
UHT800 HANDHELD MIC TRANSMITTER
OFF
OFF
ON
ON
29
30
31
32
33
34
36
35
37
29. BATTERY COVER
30. MIC BALL/ANTENNA
31. AUDIO INPUT LEVEL
32. TWO AA BATTERIES
33. POWER ON LED
34. LOW BATTERY LED
35. RF POWER SWITCH
36. AUDIO MUTE ON/OFF
37. IR RECEPTOR SENSOR/
WINDOW
38. BATTERY HOLDER
38
UHT800
