The mixer shall be the Bogen VMIX, or equivalent,
with 8 module bays capable of accepting advanced
plug-in modules, with 2 bays capable of accepting sig-
nal-processing plug-in output modules. Each channel
shall ha
v
e its o
wn independent volume control, and
LED signal/clip indicator.The mixer shall have a mas-
ter volume control, bass and treble controls, an 11-
segment LED output le
v
el meter to monitor the
output le
v
el of the mix
er with P
eak Hold meter
switch.
The mixer shall have an unbalanced output jack, a
125 Hz Lo-cut f
eatur
e
, tone control bypass switch
(balanced transf
ormer
-isolated output),
balanced
output signal level switch (-50, -
10, and +4 dBµ),
resettable circuit breaker, power indicator, and
gr
ounded uns
witched
A
C con
v
enience r
eceptacle
with a 500W maximum capacity provided for exter-
nal equipment.
For larger applications, the mixer shall be able to
bridge to another mixer using a built-in bridging jack
and mute terminals, allowing the number of inputs to
be increased.
The mixer shall have a motorized volume control
that can be remotely operated (with RVCP Remote
Volume Control Panel).
The mix
er shall be rack mountable (with RPK87 rack
mounting kit).
Security co
v
ers shall be a
vailable to
protect volume, bass, and treble controls (with
PVSC);
and 8 security co
v
ers shall be included to
pr
e
v
ent tampering with module contr
ols or to co
ver
empty module spaces (with PVMC).The mixer shall
ha
v
e a three-year warranty, shall weigh
18 lb
.,
and
measur
e
16
1
/2"
W x 3
1
/2" H x 12" D
.
Architect
and Engineer
Specifications**
50 Spring Str
eet,
Ramse
y
,
NJ 07446,
U
.S.A.
201-934-8500 FAX: 201-934-9832
Web Site: www.bogen.com
Technical
Specifications
Rear Panel
Output Level
Balanced: Selectable +4, -10, -50 dBµ (typical
with meter at “0”)
Unbalanced: 0 dBµ (typical with meter at “0”)
Max. Output Level
Balanced: +18 dBµ
Unbalanced: +20 dBµ
Frequency Response: +/- 1 dB (20 Hz to 20 kHz)
Distortion: 0.01% (@ +18 dBµ THD+N,
20-20 kHz BW Limited)
Signal-to-Noise
Fundamental: -99 dB*
w/ AUX MAX1R Module: -94 dB*
w/ MIC2X Module: -64 dB*
w/ TEL1S Module: -92 dB*
Tone Controls
Bass Frequency: 100 Hz (+/- 10 dB minimum)
Treble Frequency: 10 kHz (+/- 10 dB minimum)
Low Cut Frequency: 125 Hz @ -6 dB/octave
Signal / Clip Indicator
Signal Detect Threshold: 10 mV @ output of module
Signal Indicator Hold Time: 50 mS green indicator
Clip Detect Threshold: 6V @ output of module
Clip Detect Hold Time: 50 mS red indicator
Output Impedance
Balanced: 50 ohms @ +4 dBµ, 600 ohms @
-
10 dBµ, 5 ohms @ -50 dBµ
Unbalanced: 100 ohms
Power Consumption: 21 watts
AC Power Receptacle: 500 watts maximum power,
unswitched
Dimensions: 16
1
/2" W x 3
1
/2" H x 12" D
Product Weight: 18 lb.
Safety Approvals: cUL (U.S.A. & Canada)
* Referenced to 18 dBµ level, 20 - 20 kHz bandwidth limited.
**
Ar
chitect and Engineer Specifications ar
e a
vailable online in a
Micr
osoft®
W
or
d document to assist y
ou with pr
eparing y
our bids.
