74
Taillight Bulb Replacement
Unscrew lens screws to expose bulb.
Push bulb in and hold while turning
counterclockwise to release.
Install the new bulb by first pushing in
while turning clockwise.
1. Lens
2. Screws
Indicator Light Replacement
If one LED is burnt in the indicator light
cluster, see an authorized Bombardier
ATV dealer for replacement of the light
cluster.
Speedometer Bulbs
Each bulb can be replaced individually.
Proceed as follows:
Remove the screw on each side of the
steering cover.
Remove the choke knob lever.
1. One screw on each side
2. Remove the choke knob lever
Pull up the steering cover.
Remove the two nuts under speedom-
eter and unplug the connector.
1. Remove the two nuts
2. Unplug the connector
V01L0HY
12
2
V01A01Y
2
1
V01G06Y
1
2
vmo2000_002b.fm Page 74 Friday, September 17, 1999 10:58 AM
