-19-
Riduttore
Gearbox
Disinnesto
Disengag.
Ruota/Wheel
(max rpm)
7 06 C 2 B D 60
7 06 C 2 H D 60
7 06 C 3 H D 60
7 07 C 3 B D 40
7 09 C 2 B D 40
7 09 C 3 B D 40
7 13 C 3 B D 20
7 15 C 3 B D 20
Innestato/Engaged
Disinnestato/Disengaged
7 17 C 3 H D 20
Riduttore
Gearbox
Disinnesto
Disengag.
Ruota/Wheel
(max rpm)
7 13 C 2 B DS1 20
7 17 C 3 H DS1 20
Innestato/Engaged
Disinnestato/Disengaged
