© Copyright LOTRONIC 2015
• Unplug unit from the wall outlet before cleaning. Never use benzene,
thinner or other flammable solvents for cleaning. Use only a soft damp
cloth.
• The power supply cord of the unit should be unplugged from the wall
outlet when it is to be unused for a long period of time.
• Care should be taken so that objects and liquids are not spilled into the
enclosure through any openings.
• This unit should be serviced by qualified service personnel when the
power cord or the plug has been damaged; objects or liquid have been
spilled into the unit; the unit has been exposed to rain or liquids of any
kind; the unit does not appear to operate normally or exhibits a marked
change in performance; the device has been dro
pped or the encl
osure
damaged.
• DO NOT ATTEMPT SERVICING OF THIS UNIT YOURSELF.
• REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
Upon completion of any servicing or repairs, request the service shops
assurance that only Factory Authorized Replacement Parts with the same
characteristics as the original parts have been used and that the routine safety
checks have been performed to guarantee that the equipment is in safe
operating condition.
REPLACEMENT WITH UNAUTHORIZED PARTS MAY RESULT IN FIRE.
Façade:
1.Power Switch 2.MIC 1 Input
3. MIC 2 Input 4.MIC Volume
5. MIC Echo 6.Master Volume
7.Master Bass 8.Master Treble
9.Audio Input selection of AUX/TAPEVCD
Arrière:
1. VCD Audio input 2. TAPE Audio input
3. AUX Audio input 4. Line Audio output
5. Audio output for right master speaker 6. Audio output for left
7. AC Power supply cord 230V/50Hz master speaker
8. Fuse
Connecting the system:
10. Headphone input
