Troubleshooting
Problem Possible cause Solution
No sound output when
power on
1: No input sound source 1:Connect a Line signal
2: Volume in the lowest position 2: Adjust volume
3: USB/TF not connected 3: Insert a USB/TF Card
Distortion of sound
1:Volume too loud 1: Turn volume lower
2: Audio file error 2: Check and change the audio file
3: Adjust Bass/Treble by “MENU” and
“Main volume”
No sound from the
Microphone
1:Microphone socket not fully plugged in 1: Completely plug in the microphone
socket
2: Microphone switch is not on 2: Power on microphone
3: Microphone volume too low 3: Adjust microphone volume
No sound from the
USB/TF card
1:incompatible song format 1: songs format should be MP3/WMA
2: Illegal operation causes failures 2: Power off, then power on
3:USB/TF Card not inserted properly 3: Insert USB/TF card properly
Speaker makes much
noise
1: Wired Microphone too close to the
speaker
1: Do not let the wired microphones head
point at the speaker
2: Wired Microphone is switched on but
not in use
2: Turn off wired microphone if not in use
3: Microphone volume too loud 3: Reduce the microphone volume
4: Mobile phone too close to the speaker 4: Keep mobile away from the speaker
during calls
5: Too close to the equipment which inter
-
feres with the speaker
5: Keep the speaker away from other
sources of interference
Blue-connect Failure
1: Blue-connect Disconnected 1: Find the right device Name or press
"MENU" Button to restore factory set-
tings.
2: Blue-connect Connected but no voice 2: Confirm if you are connected to the
right device Name
3: Blue-connect effective distance too
short
3: Try to keep away from barriers, such as
walls, glasses…etc
Specifications
Max. power ..............................................................................................................................................................................280W
Woofer .......................................................................................................................................................................2 x 6.5"/16cm
Freq. range ................................................................................................................................................................ 100Hz-18kHz
FM band ........................................................................................................................................................... 87.5MHZ – 108MHz
S/N ratio ................................................................................................................................................................................ ≥75dB
BT frequency ......................................................................................................................................................... 2402-2480MHz
BT Max RF Power .......................................................................................................................................................... -0,91dBm
Power supply .................................................................................................................................. 5V𝌃 2A via supplied USB lead
Built-in battery ..............................................................................................................................................Lithium 3.7V𝌃 3.6Ah
Dimensions ..................................................................................................................................................... 290 x 280 x 660mm
Weight ..................................................................................................................................................................................... 3.9kg
The product design and specifications may be changed without prior notice!
