Booth BRW181E - Introduction and Specification; Product Introduction; Product Specification Details

2
Contents
Section
Page
Section
Page
Introduction & Specification
2
Schematics
4 - 6
Model Numbering, Installation &
Commissioning
3
Replacement Parts, Removal,
transportation and Disposal
7
Introduction
The BRW18# models are a range of mini-remote coolers with various control options of mechanical,
digital and energy saving digital thermostats. They also incorporate various product coil configurations
and pump options, including variants for “SCOPE” installations that use pythons with tube-in-tube
systems. The model options are covered on the following pages as well as wiring schematics for the
units fitted with the mechanical & digital controllers.
Specification
Dimensions
(approx.)
450mm(W)
485mm(D)
725mm(H) – 2 Stage variants
745mm(H) – 3 & 4 Stage variants
770mm(H) – SCOPE variants
Compressor
SCOPE Variants
Huyai (Cubigel)
GPY16Lab
Other models
Danfoss
FR11G
Dry Weight
Nominal 36 Kg (will vary
depending on unit type)
This product contains fluorinated
greenhouse gas with a GWP of 1400 in an
hermetically sealed system
Wet Weight
Nominal 68.5 Kg
Supply
230Vac/50Hz
Refrigerant = R134a
200g
180g
Rated Input
450W
700W
Climatic Class
N
Rated Current
3.5A
3.5A
Nominal ice bank
18kg
Fuse Rating
5A
5A
IP Rating
N/A
