Introduction
The EXL95H & EXL96H units are med/high capacity chillers incorporating soda recirculation which
include an option of a cold carbonator incorporating soda recirculation. It is designed in a modular fashion
to cover a range of control options, with a single mechanical thermostat, or a choice of two digital
thermostats which are specified at time of order. They also have the capacity to incorporate up to 6 syrup
cooling coils.
The wiring schematics included in the following pages reflect this modularity:
Safety
The EXL95H/96H models use a R290 (Care 40, Propane) refrigerant. Below are some safety points
which the end user must adopt to mitigate the risk of unsafe conditions arising.
Service must only be carried out by a suitably qualified refrigeration engineer.
The unit must be isolated from the electricity supply before removal of the covers.
Do not damage the refrigeration circuit.
Ventilation openings must be clear of obstructions.
There must be a gap of at least 100mm between the appliance and a wall or other restriction.
Where electrical components are replaced, the new component must be of the same type.
Operate the unit within (ambient) operating temperatures; 10⁰C to 32⁰C.
