Bosch 1619EVS Parts List

67 1 601 030 022 Clip {2} 9
68 2 610 997 003 Button 63
69 2 610 996 138 Spring Clip 27
70 2 610 996 139 Cover Plate 64
73 2 610 996 141 Indicator Ring 9
74 2 610 991 306 Screw {2} 89
75 2 610 907 721 Shield 9
76 2 910 611 018 Screw {2} 89
77 2 610 996 142 Screw 89
78 3 603 415 560 Screw {5} 89
79 2 610 996 143 Screw {2} 89
80 2 610 913 441 Screw {5} 89
81 2 914 411 046 Screw {11} 89
84 2 910 951 118 Screw {2} 89
87 2 610 913 573 O-Ring 78
88 2 610 997 008 Washer 65
89 2 610 997 030 Terminal {4} 10
90 2 610 997 031 Cable 10
91 2 610 913 825 Screw LH 89
92 2 610 909 072 Press Nut 85
93 2 916 030 008 Lock Washer 65
94 2 610 001 734 Lock Washer 65
651 2 610 991 370 Adaptor 9
652 2 910 861 120 Screw {2} 89
653 2 610 992 417 Wrench 24mm 9
654 2 610 907 529 Extension Assembly 9
w/pos. 654/3
654/3 2 610 015 629 O-Ring {2} 78
724 2 610 906 283 1/4" Collet Assembly 91
724.1 2 610 906 287 3/8" Collet Assembly 91
724.2 2 610 906 284 1/2" Collet Assembly 91
804 2 610 997 157 Switch On/Off 15
w/pos. 18
805 3 604 460 515 Cord 11
810 2 610 997 152 Brush Set 26
834 2 610 996 147 Base Assembly 88
840 2 610 910 606 Shaft Lock Assembly 54
852 2 610 997 148 Lock Lever Assembly 64
854 2 610 914 129 Fine Adjustment Assy. 9
855 2 610 996 149 Gear & Shaft Assembly 32
w/pos. 87
1 2 610 996 079 Motor Housing 71
2 2 610 996 096 Field 120V 22
3 2 610 996 097 Armature 120V AW
3/14 2 916 650 014 Retaining Ring 89
5/1 2 610 316 596 Terminal {2} 10
6 3 600 707 506 Strain Relief 6
7 2 601 035 001 Cord Clamp 89
8 2 610 907 981 Nameplate 9
9 2 610 998 370 Label 9
13 1 900 905 276 Ball Bearing 60
14 3 600 900 526 Ball Bearing 61
16 1 604 336 008 Brush Holder {2} 25
18 2 610 904 114 Screw {4} 89
19 2 910 611 020 Screw {2} 89
20 2 610 998 371 Label Caution 9
21 1 614 652 001 Brush Spring {2} 27
22 2 610 996 101 Cable {2} 10
23 2 610 996 102 Bearing Sleeve 82
27 2 610 996 083 Housing Cover 70
28 2 610 996 148 Fan Housing Assembly 73
30 2 610 996 106 Right Handle Assembly 74
31 2 610 996 107 Left Handle Assembly 74
35 2 610 996 111 Sub-Base 88
36 2 916 011 892 Washer {3} 65
41 3 600 149 500 Circlip 89
42 2 610 302 855 Retaining Ring 89
43 2 610 996 118 Baffle 24
44 2 610 996 119 Lock Rod 88
45 2 610 996 120 Spring 27
47 1 607 233 147 Speed Control 17
48 2 610 996 122 Bellows {2} 9
49 2 610 997 139 Nut 85
50 2 610 996 125 Lock Bolt LH 89
53 2 610 996 128 Spring 27
59 2 610 913 476 Washer 65
60 2 600 590 006 Cap/Spring 80
61 3 603 231 539 Knob 63
62 2 610 996 135 Lock Lever 64
63 2 610 996 136 Depth Stop 87
65 2 610 909 058 Screw 89
66 2 610 996 137 Spring Washer 65
Pos. Part Number Description {Qty.} F/C Pos. Part Number Description {Qty.} F/C
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
1619EVS PLUNGE ROUTER
Service Notes:
