Bosch AdvancedRotak 770 User Manual

English | 15
Bosch Power Tools F 016 L81 572 | (11.12.17)
Noise/Vibration Information
Sound emission values determined according to EN 60335-2-77.
Mounting and Operation
Lawnmower
AdvancedRotak
760 770 780 790
Article number
3 600 HB9 ...
... 301/371 ... 302/372 ... 303/373 ... 304/374
Rated power input
W 1800 1800 1800 1800
Rated voltage
V 220 – 240 220 –240 220 – 240 220 – 240
Bowl diameter
cm 46 46 46 46
Height of cut
mm 20 – 80 20 – 80 20 – 80 20 – 80
Grassbox, capacity
l5050 50 50
Weight according to EPTA-
Procedure 01:2014
kg 16.0 16.0 16.0 16.0
Protection class
/II /II /II /II
Serial number
see type plate on the garden product
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
All values in this manual are measured for usage below or equal to 2000 meters above nominal sea level
Advanced
Rotak 650 660 670 690 750 760 770 780 790
3 600 HB9 ... ... 200
... 230
... 270
... 201
... 271
... 202
... 272 ... 204
... 300
... 370
... 300
... 371
... 302
... 372
... 303
... 373
... 304
... 374
Typically the A-weighted
noise levels of the product
are:
Sound pressure level
Sound power level
Uncertainty K
dB(A)
dB(A)
dB
76
89
=1.0
76
89
=1.0
76
89
=1.0
76
89
=1.0
76
89
=2.0
76
89
=2.0
76
89
=2.0
76
89
=2.0
76
89
=2.0
Vibration total values a
h
(triax vector sum) and un-
certainty K determined ac-
cording to
EN 60335-2-77:
Vibration emission value
a
h
Uncertainty K
m/s
2
m/s
2
<2.5
=1.5
<2.5
=1.5
<2.5
=1.5
<2.5
=1.5
<2.5
=1.5
<2.5
=1.5
<2.5
=1.5
<2.5
=1.5
<2.5
=1.5
Action Figure Page
Delivery Scope 1 235
Unfold handle
Adjusting the Working Height
2 236
Grassbox fitting/removing
3 237
Adjusting the Cutting Height
4 238
Connecting the extension lead
5 239
Starting
6 239
Working Advice “mowing”
6 239
Stopping 6 239
Working Advice
7 240
Level Indicator Grassbox emp-
ty/full
8 240
Fold down handle
9 241
Blade Maintenance/Blade Swap
10 242
Selecting Accessories
11 242
Action Figure Page
OBJ_BUCH-3146-003.book Page 15 Monday, December 11, 2017 8:42 AM

Bosch AdvancedRotak 770 Specifications

General

Brand	Bosch
Model	AdvancedRotak 770
Category	Lawn Mower
Language	English
