The requested motor output is shown on the display
(a). The maximum motor output depends on the se-
lected assistance level.
When the on-board computer is removed from the
holder (4), the last indicated assistance level is
stored; the motor-output indicator (a) remains
empty.
Interaction between the eBike system and
gear-shifting
The gear-shifting should be used with an eBike drive
in the same way as with a normal bicycle (observe the
operating instructions of your eBike on this point).
Irrespective of the type of gear-shifting, it is advisable
that you briefly stop pedaling when changing gear.
This will aid the gear change and reduces wear on the
powertrain.
By selecting the correct gear, you can increase your
speed and range while applying the same amount of
force.
For this reason, follow the gear change recommenda-
tions provided by the indicators (g) and (h) on your
display. If indicator (g) is displayed, you should
change to a higher gear with lower cadence. If indica-
tor (h) is displayed, you should select a lower gear
with higher cadence.
Switching bike lights on/off
In the model in which the lighting is powered by the
eBike system, the front and rear lights can be
switched on and off at the same time via the on-board
computer with button (2).
When the lighting is switched on, <Lights on> ap-
pears and when the lighting is switched off, <Lights
off> appears for approx. 1s on the text indicator (d).
The lighting symbol (c) is displayed when the light is
on.
The on-board computer saves the light status and ac-
tivates this saved status accordingly after a restart.
Switching the bike light on and off has no effect on
the back lighting of the display.
Switching the push assistance on/off
The push assistance aids you when pushing your
eBike. The speed of this function depends on the se-
lected gear and can reach a maximum of 3.7mph.
The lower the selected gear, the lower the speed of
the push assistance function (at full power).
u The push assistance function must only be used
when pushing the eBike. There is a risk of injury if
the wheels of the eBike are not in contact with the
ground while using the push assistance.
To activate the push assistance, briefly press the
WALK button on your on-board computer. After acti-
vation, press the + button within 3s and keep it
pressed. The eBike drive is switched on.
Note: The push assistance cannot be activated at as-
sistance level OFF.
The push assistance is switched off as soon as one of
the following occurs:
– You release the +button;
– the wheels of the eBike are locked (e.g. by applying
the brakes or hitting an obstacle);
– the speed exceeds 3.7mph.
The push assistance function is subject to local regu-
lations; the way it works may therefore differ from the
description above. It can also be deactivated.
Displays and settings of the on-
board computer
Speed and distance indicators
The speedometer(f) always displays the current
speed.
You can choose from the following functions in the
function display (combination of text indicator(d)
and value indicator(e)):
– <Clock>: Current time
– <Max. speed>: Maximum speed achieved since the
last reset
English – 9
Bosch eBike Systems 1 270 U20 XBI | (28.02.2019)
English – 10
1 270 U20 XBI | (28.02.2019) Bosch eBike Systems
– <Avg. speed>: Average speed achieved since the
last reset
– <Trip time>: Journey time since the last reset
– <Range>: Estimated range of the available battery
charge (at constant conditions such as assistance
level, route profile, etc.)
– <Odometer>: Total distance traveled with the
eBike (cannot be reset)
– <Trip distance>: Distance traveled since the last
reset
To switch between display functions, press
theibutton (1) on the on-board computer or
theibutton(10) on the operating unit repeatedly un-
til the required function is displayed.
To reset the <Trip distance>, <Trip time> and
<Avg. speed>, switch to one of these three functions
and then press and hold the RESET button (6) until
the indicator is set to zero. This will also reset the val-
ues of the other two functions.
To reset the <Max. speed>, switch to this function
and then press and hold the RESET button (6) until
the indicator is set to zero.
To reset the <Range>, switch to this function and
then press and hold the RESET button (6) until the in-
dicator is reset to the value of the factory setting.
If the on-board computer is removed from the holder
(4), all values of the functions are saved and can still
be displayed.
Displaying/adjusting basic settings
The basic settings can be displayed and changed re-
gardless of whether the on-board computer is in-
serted in the holder (4) or not. Some settings can
only be viewed and changed when the computer is in-
serted. Depending on the equipment of your eBike,
some menu items may not be present.
To go to the basic settings menu, simultaneously
press and hold the RESET button (6) and the i button
(1) until <Configuration> appears in the text indica-
tor (d).
To switch between the basic settings, press the i
button (1) on the on-board computer repeatedly until
the required basic setting is displayed. If the on-
board computer is inserted in the holder (4), you can
also press the i button (10) on the operating unit.
To change the basic settings, press the on/off but-
ton(5) next to the –indicator to reduce or scroll
down, or the lighting button(2) next to the +indica-
tor to increase or scroll up. If the on-board computer
is inserted in the holder (4), it is also possible to
change the settings with the – (11) and + (12) but-
tons on the operating unit.
To exit the function and save a changed setting, press
the RESET button (6) for 3s.
You can choose between the following basic settings:
– <– Clock +>: Setting the current time. The time can
be changed faster by pressing the setting buttons
for longer.
– <– Wheel circum. +>: Changing the value pre-set
by the manufacturer by±5%. This menu item is dis-
played only when the on-board computer is in the
holder.
– <– English +>: Changing the language of the text
indicator. You can choose between German, Eng-
lish, French, Spanish, Italian, Portuguese, Swedish,
Dutch and Danish.
– <– Unit km/mi +>: Displaying the speed and dis-
tance in either kilometers or miles.
– <– Time format +>: Displaying the time in 12-hour
or 24-hour format.
– <– Shift recom. on +>/<– Shift recom. off +>:
Switching the shift recommendation display on or
off.
– <Power-on hours>: Total time traveled with the
eBike (cannot be changed)
– <Displ. vx.x.x.x>: Display software version.
– <DU vx.x.x.x>: Drive unit software version. This
menu item is displayed only when the on-board
computer is in the holder.
