CM710B Specifications
Part Number: CM710B - 4 Way Relay Output Expander Module (RS485 LAN)
Operating Voltage: 10.0V DC. - 14.5V DC. @ 30mA Max 200mA. ( All relays and LEDs Operated)
Outputs: 4 x Form C Relay Outputs - Contact rated at 24V DC @2A Max
Module Connection:
(RS485 LAN)
Max total LAN length using multi strand security cable = 300m ,
Max total LAN length using 2 pair twisted shielded data cable (Belden 8723) = 1200m.
See manual for complete wiring instructions.
Operating
Environment:
0˚ to 55˚C RH 5 to 85% at 30˚C non-condensing.
Fixing Method:
The CM710B can be mounted in the MW700, MW710, MW720 or MW730 enclosures using clip in
PCB mounts supplied.
Warranty: 3 years from date of manufacture (return to base)
N12138N12138
RoHS

In the interest of ongoing product development this
document is subject to change without notice.
Output Defaults - Solution 16i Panels
The table below list the default values for all output parameters in the Solution 16i panel. Outputs 1 to 4 are high
current digital outputs. Outputs 5 to 8 are only available if the optional output expander board (CM710B) is fitted.
Options marked N/A = Not Applicable.
Solution 16i Default Output Programming
Programming Option Output 1 Output 2 Output 3 Output 4 Output 5-8
Output Name
External
Siren
Strobe
Light
Smoke Sensor
PWR
Internal
Siren
Output ?
Name
Event Type
36
(External
Siren)
48
(Strobe)
49
(Smoke
Sensor GND)
37
(Internal
Siren)
0
Event Assignment 0 0 0 0 0
Output Polarity 14 6 11 6 0
Time Parameter
N° Of Hours 000 008 000 000 000
N° Of Minutes 005 000 000 005 000
N° Of Seconds 000 000 010 000 000
N° Of 1/10 Seconds 000 000 000 000 000
Output Options
Do not Operate If Low Battery Y Y Y Y N
Display Output Overload Y Y Y Y N/A
Report Output Overload Y Y Y Y N/A
Display Missing Output Device Y N N N N/A
Report Missing Output Device Y N N N N/A
Alarm On Device Fail N N N N N/A
Block Output If Armed All On N N N N N
Display Status On Keypad N N N N N
Table 7: Solution 16i Output Defaults
