Bosch FPA-5000 Wiring Guide

CZM 0004 A
AUX1
+
–
AUX2
+
–
OUT1
–
+
OUT2
–
+
IN1
–
+
IN2
–
+
IN3
–
+
IN4
–
+
OUT3
–
+
OUT3
–
+
AUX3
+
–
AUX4
+
–
b2
b1
c
a1/
a2
red black blue
MSS 300--WH--EC
ROT SCHWARZ BLAU
RED BLACK BLUE
b2
b1
c
a1/
a2
red black blue
MSS 300--WH--EC
ROT SCHWARZ BLAU
RED BLACK BLUE
MSS 300-WH-EC
FLM--420--NAC--S
IN OUT
LSN FAIL
a1- b1+ a2- b2+ ac bat
b a b a 0V 24V
--U+U
24 V -- 28 V
FLM-320-EOL2W
EN54-13
116 en | Wiring Modular Fire Panel
2016.07 | 12.6 | F.01U.009.201 Wiring Guide Bosch Sicherheitssysteme GmbH

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
