Bosch FPA-5000 - Page 167

DIBT
ED 100
ED 250
(+Upgrade Card B
FLM--420--RHV
NC COM NO
REL1
NC COM NO
REL2
b1+ a- b2+
LSN FB2 FB1
–
+ +
ED 100/ED 250
6 1
B
FMC-210-DM-G-R
230 VAC
+
-
LSN
LSN
Modular Fire Panel Wiring | en 167
Bosch Sicherheitssysteme GmbH Wiring Guide 2016.07 | 12.6 | F.01U.009.201
