8
Assembly
Inserting and Releasing
Battery Pack
Ensure the switch is in
the off position before
inserting battery pack. Inserting the battery
pack into power tools that have the switch on
invites accidents.
Slide charged battery pack 3 into the housing
until the battery pack locks into position (Fig.
2).
Your tool is equipped with a secondary locking
latch to prevent the battery pack from
completely falling out of the tool housing,
should it become loose due to vibration.
To remove the battery pack 3, press the
battery pack release button 7 and slide the
battery pack forward (Fig. 2).
Press the battery pack release button 7 again
and slide the battery pack completely out of
tool housing (Fig. 2).
