Bosch GRL2000-40HV - Page 12

-12-
Rotational Laser Level GRL2000-40H GRL2000-40HV
Working range (Diameter)
–without laser receiver
–with laser receiver
approx. 200 ft
(approx. 60 m)
approx. 2000 ft
(approx. 600 m)
approx. 200 ft
(approx. 60 m)
approx. 2000 ft
(approx. 600 m)
Leveling Accuracy
1) 2)
– Horizontal
– Vertical
±1/16 in at 100 ft
(±1.5 mm at 30 m)
±1/16 in at 100 ft
(±1.5 mm at 30 m)
±1/8 in at 100 ft
(±3 mm at 30 m)
Self-leveling range ±8% (±4.6°) ±8% (±4.6°)
Singe/dual-axis slope operation 8% 8%
Le
veling duration approx 30s approx 30s
Rotational speed 600min
-1
0/150/300/600min
-1
Scan angle for line operation — 10º/25º/50º
Operating temperature 14 °F ~122 °F
(–10 °C ~ +50 °C)
14 °F ~122 °F
(–10 °C ~ +50 °C)
St
orage temperature -4 °F ~ 158 °F
(–20 °C ~ +70 °C)
-4 °F ~ 158 °F
(–20 °C ~ +70 °C)
Relative air humidity, max. 90 % 90 %
Laser class 3R 3R
Laser type 635 nm, <5 mW 635 nm, <5 mW
Laser beam Ø at the exit
opening, appro
x.
1)
0.2 in (4 mm) 0.2 in (4 mm)
Tripod mount 5/8 in-11 5/8 in-11
Batteries (alk
ali-manganese) 2 x 1.5 VD (LR20) 2 x 1.5 VD (LR20)
Operating life time, approx.
–Batteries
(alkali-manganese)
1)
30 h 30 h
Weight 3.9 lb (1.86 kg) 3.9 lb (1.86 kg)
Dimensions 7.4 x 7.2 x 6.7 in
(187 x 182 x 170 mm)
7.4 x 7.2 x 6.7 in
(187 x 182 x 170 mm)
Degree of protection IP 56 IP 56
1) at 68º F (20 ºC).
2) alongside the axes.
