4
2 609 931 938 • TMS • 24.11.99
Battery-Powered Screwdriver GSR 9,6-1 GSR 12-1
Part number 0 601 955 6.. 0 601 955 5..
No-load speed 0–600 per min. 0–700 per min.
Torque adjustment range 1–7 Nm 1–8 Nm
Torque, max. in position “ ”:
Soft screwdriving case 9 Nm 10 Nm
Hard screwdriving case 24 Nm 26 Nm
Drill dia. steel 10 mm 12 mm
Drill dia. aluminium 12 mm 15 mm
Drill dia. wood 15 mm 18 mm
Screw diameter max. 6 mm max. 6 mm
Drill chuck clamping range 1.0–10 mm 1.0–10 mm
Drill spindle threads 3/8 " 3/8 "
Weight with battery Approx. 1.4 kg Approx. 1.5 kg
Battery NiCd NiCd
Temperature monitor NTC NTC
Rated voltage 9.6 V= 12 V=
Weight Approx. 0.5 kg Approx. 0.6 kg
1
Torque setting ring
2
Quick clamping drill chuck
3
On/Off Switch/Speed control
4
Rotational direction switch with lock-off
5
Screwdriver bit
6
Battery
7
Drill magazine*
8
Screwdriver bit magazine*
9
Ventilation slots
10
Carrying strap*
11
Adjusting slide
12
Press-in area
* Optional Extras
*
Not all the illustrated or described accessories are
included as standard delivery.
The machine is intended for the screwing in and
loosening of screws as well as drilling in wood,
metal, ceramics and plastic.
Working safely with this machine
is possible only when the operat-
ing and safety information is
read completely and the instruc-
tions contained therein are
strictly followed. In addition, the
general safety instructions in the
enclosed booklet must be fol-
lowed. Before using for the first
time, ask for a practical demon-
stration.
Be careful of hidden electrical lines
or gas and water pipes. Check the
working area, e. g., with a metal de-
tector.
If you have long hair, wear a protec-
tive hairnet. Work only with close-fit-
ting clothes.
Before each use, check the machine and bat-
tery. If damage is detected, do not use the ma-
chine. Have repairs performed only by a quali-
fied technician. Never open the machine your-
self.
The battery and charger match up. For charg-
ing, use only a Bosch charger intended for this
purpose.
Tool Specifications
GB
Operating Controls
Intended Use
For Your Safety
