Workshop Manual
Smart Tachograph EFAS-4.10/4.11
Chapter 12 List of the events/malfunctions and measures for trouble-shooting
Abbreviations and explanations:
SrvID Service ID (EFAS service code)
EFT Event fault type, error code in accordance with EU Regulation (EC) No. 2016/799
DTC Diagnostic trouble code (standardized automotive error code)
dec Decimal (base 10 numeral system)
hex Hexadecimal numeral system with a base of 16 (using characters 0 to 9 and A to F)
12.1 EFT summary table
The following table provides an overview of the types of error code specied for digital tachographs in accordance with EU
Regulation (EC) No. Set 2016/799.
The error code types appear on the printouts and in the downloaded data in hexadecimal (hex) format.
Table 16 — EFTs and corresponding SrvIDs
EFT
(hex)
Meaning SrvIDs
0x0x General events
0x00 No further details
11
0x01 Invalid card inserted S7, S8, S117, S118, S140, S141, S142, S143, S144, S145
0x02 Smart-card conict S69
0x03 Time overlap S9, S10
0x04 Driving without suitable smart-card S67
0x05 Card inserted while driving S11, S12
0x06 Last use of smart-card not fully completed S13, S14
0x07 Speed infringement S70
0x08 Power supply outage S3, S6
0x09 Sensor data errors S22, S23, S24, S25, S101
0x0A Vehicle motion data conict (IMS) S83
0x0B Time conict (between GNSS and EFAS system
clock)
S86
0x0C Communication error with the remote communi-
cation equipment
S174
0x0D Missing position data of the GNSS receiver S171
0x0E Communication error with external GNSS
equipment
n.a.
0x1x Security breach of the vehicle unit
0x10 No further details
11
0x11 Authentication failure of the speed sensor S28, S84
0x12 Failure to authenticate the tachograph card S19, S20
0x13 Unauthorized replacement of the speed sensor S29
0x14 Integrity error in the card data S15, S16, S90, S91
0x15 Integrity error in the stored user data S36, S71, S82, S106
0x16 Internal error during data transfer S72
0x17 Unauthorized opening of the tachograph housing S73
0x18 Hardware sabotage S17, S18, S30, S68, S93
0x19 GNSS manipulation detection n.a.
0x1A Authentication error of external GNSS equipment n.a.
0x1B Expired external GNSS equipment certicate n.a.
0x2x Security breach of the sensor
0x20 No further details S85
0x21 Authentication error S27
0x22 Integrity error in the stored data S26
0x23 Internal data transfer error S75
11 EFTs without proper SrvID are not supported by EFAS
