Installation/configuration notes
The cabinet is designed for both surface and recessed
mounting on walls. The back box provides a selection
of mounting holes, even for mounting on U40 and MK
installation boxes. The back box has two knockout
holes on the topside for two cable glands (not
included) for loop-through connection. For extra
installation convenience, a safety cord from the back
box lets the installer temporarily hang the front grille
unit during installation.
The cabinet has a three-way terminal block with screw
connections suitable for loop-through wiring (including
earth).
Four primary taps on the matching transformer allow
selection of nominal full-power, half-power, quarter-
power or eighth power radiation (in 3 dB steps).
61.5 mm (2.4")
105 mm (4.1")
170 mm (6.7")
199 mm (7.8")
196 mm (7.7")
Dimensions in mm (in)
60 mm (2.3")
6 mm (0.23")
10 mm (0.3")
4 mm (0.15")
115 mm (4.5")
60 mm (2.3")
36 mm (1.4")
7 mm (0.27")
4.8 mm (0.2")
20 mm (0.7")
20 mm (0.7")
20 mm (0.7")
Rear / Installation dimensions in mm (in)
Surface mounted (left) and recessed mounted (right)
4
C
6W
3W
1.5W
0.75W
-
70V
C
-
6W
3W
1.5W
0.75W
100V
Circuit diagram
60
70
80
90
100
110
10 100 1000 10000 100000
dB SPL
Frequency response
-30
-25
-20
-15
-10
-5
0
5
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
1000 2000 4000 8000
-30
-25
-20
-15
-10
-5
0
5
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
125 250 500 1000
Polar diagrams (measured with pink noise)
