Bosch Performance Line Original Operating Instructions

136
English – 2
(6)
Holder
(7)
Select button
(8)
Diagnostics connection (for servicing purposes
only)
(9) Button for decreasing assistance level –/
walk assistance
(10) Button for increasing assistance level +/
bicycle lights
(11)
Button to reduce brightness/
go back
(12)
Button to increase brightness/
go forward
Technical data
Operating unit LED Remote
Product code BRC3600
Max. charging current of USB
port
A)
mA 600
USB port charging voltage
A)
V 5
USB charging cable
B)
USB Type-C®
C)
Charging temperature °C 0to+45
Operating temperature °C –5to+40
Storage temperature °C +10to+40
Diagnostic interface USB Type-C®
C)
Internal lithium-ion battery V
mAh
3.7
75
Protection rating IP55
Dimensions (without fastening) mm 74×53×35
Weight g 30
Bluetooth® Low Energy 5.0
– Frequency MHz 2400–2480
– Transmission power mW 1
A)
Specification for charging theLED Remoteoperating unit; ex-
ternal devices cannot be charged.
B) Not included with the product as standard
C) USBType-C® and USB-C® are trademarks of USB Implementers
Forum.
The licence information for the product can be accessed at the follow-
ing Internet address: www.bosch-ebike.com/licences
Declaration of Conformity
Robert Bosch GmbH, Bosch eBike Systems, hereby declares
that theLED Remoteradio communication unit complies
with Directive 2014/53/EU. The full text of the EU Declara-
tion of Conformity can be accessed at the following Internet
address: www.bosch-ebike.com/conformity
.
Robert Bosch GmbH, Bosch eBike Systems, hereby declares
that the LED Remote radio communication unit complies
with the Radio Equipment Regulations 2017 (SI
2917/1206). The full text of the UK Declaration of Conform-
ity can be accessed at the following Internet address:
www.bosch-ebike.com/conformity
.
Operation
Requirements
The eBike can then only be switched on when the following
requirements are met:
– A sufficiently charged eBike battery is inserted (see oper-
ating instructions for the eBike battery from the system
generationthe smart system).
– The speed sensor is connected properly (see operating
instructions for the drive unit from the system genera-
tionthe smart system).
Before riding off, ensure that the buttons on the operating
unit are within easy reach. We recommend that you align the
unit so that the plus/minus button level is perpendicular to
the floor.
Operating unit power supply
If a sufficiently charged eBike battery is inserted into the
eBike and the eBike is switched on, then the internal operat-
ing unit battery is powered and charged.
If the state of charge of the internal operating unit battery is
very low, you can charge it via the diagnostics connec-
tion(8) with a USB Type-C® cable using a power bank or an-
other suitable power source (charging voltage5VV; char-
ging current max.600mAmA).
Always close the flap of the diagnostics connection(8) so
that no dust or moisture can enter.
Switching the eBike On and Off
To switch on the eBike, briefly press the on/off button(2).
After the starting animation, the state of charge of the eBike
battery is displayed in colour with the battery charge indic-
ator(3) and the set assistance level with the(5)display. The
eBike is ready to ride.
The display brightness is controlled by the ambient light
sensor(1). Therefore, do not cover the ambient light
sensor(1).
The drive is activated as soon as you start pedalling (except
at assistance level OFF). The drive power varies depending
on the assistance level set.
As soon as you stop pedalling when in normal operation, or
as soon as you have reached a speed of25/45km/h, the
drive switches off the assistance. The drive is automatically
reactivated as soon you start pedalling again and the speed
is below25/45km/h.
To switch off the eBike, press the on/off button(2) briefly
(<3s). The battery charge indicator of the eBike battery(3)
and the assistance level LED(5) go out.
If no power is drawn from the drive for about10minutes
(e.g. because the eBike is not moving) and no button is
pressed, the eBike will switch off automatically.
0 275 007 3RL | (21.02.2023) Bosch eBike Systems

Bosch Performance Line Specifications

General

Motor Type	Mid-drive
Drive Unit Weight	3.2 kg
Nominal Power	250 W
Walk Assistance	Yes
Battery Voltage	36 V
Max Speed	25 km/h (EU), 20 mph (US)
Assistance Levels	Eco, Tour, Sport, Turbo
Display	Intuvia, Nyon, Purion, Kiox
Compatibility	Bosch eBike systems
