6
Parts List
Refer to Parts List below and on pages 7–9.
• If ANY of the parts is missing,
DO NOT attempt to assemble, install, or use your
router table until the missing parts have been found
or replaced and your router table has been properly
and correctly assembled per this manual.
• For missing parts or technical assistance,
call 1-877-BOSCH99 (877-267-2499).
• In order to simplify handling and to minimize any
damage that may occur during shipping, your
router table comes unassembled.
• Separate all parts from the packaging materials
and check each part against the illustrations and
the parts lists on pages 6–9, to make sure that all
parts have been included. Do this before discarding
any of the packaging material.
Key No. Description Quantity
A ROUTER TABLE ASSEMBLY
1 Router Table 1
2 Fence Support Bracket 2
3 Fence Guide (Black) 2
4 Clamping Knob (Black) 4
5 Router Adapter Plate (Gray) 1
6 Guard Bracket 1
7 Lower Fence 2
8 Upper Fence 1
9 Fence Clamping Knob (Black) 4
10 Dust Collector (Black) 1
11 Upper Fence End Cap (Right Side, Black) 1
12 Upper Fence End Cap (Left Side, Black) 1
13 Lower Fence End Cap (Right Side, Black) 2
14 Lower Fence End Cap (Left Side, Black) 2
15 Leg Reinforcement 4
16 Table Top Insert w/ 1″ Dia. Hole (Red) 1
17 Table Top Insert w/ 2″ Dia. Hole (Red) 1
18 Table Top Insert w/ 2
3
⁄4″ Dia. Hole (Red) 1
19 Table Leg (Blue) 2
20 Fascia/Switch Assembly 1
21 Leg Storage Panel (Black) 1
22 Leg Cord Wrap Assembly (Black) 1
23 Feather Board (Blue or Gray) 2
24 Threaded Support Rod 2
25 Router Shield (Guard) 1
26 Knurled Adjustment Nut 8
27 Plastic Spacer Washer 2
28 Starter Pin 1
29 Starter Pin Guard 1
MANUALS (NOT SHOWN)
52 BOSCH RA1180 Router Table Owner’s Manual 1
53 Warranty Card 1
