-17-
Rotary Laser GRL4000-80CH GRL4000-80CHV
Weight according to EPTA-Procedure 01:2014
– with rechargeable battery
G)
– with non-rechargeable batteries
9.3−10.6 lb (4.2-4.8 kg)
10 lb (4.6 kg)
9.3−10.6 lb (4.2-4.8 kg)
10 lb (4.6 kg)
Dimensions (length × width × height) 12.8 x 7.4 x 11 in
(327 × 188 × 278 mm)
12.8 x 7.4 x 11 in
(327 × 188 × 278 mm)
Protection rating IP 68 IP 68
If mounted on a tripod, drop-proof to a height of 6 ft (2 m) 6 ft (2 m)
Recommended ambient temperature
during charging
32 °F ~ 95 °F
(0 °C to +35 °C)
32 °F ~ 95 °F
(0 °C to +35 °C)
Permitted ambient temperature
– during operation
H)
– during storage
14 °F ~ 122 °F
(–10 °C to +50 °C)
-4 °F ~ 122 °F
(–20 °C to +50 °C)
14 °F ~ 122 °F
(–10 °C to +50 °C)
-4 °F ~ 122 °F
(–20 °C to +50 °C)
Batteries Bosch GBA18V40 Bosch GBA18V40,
GBA18V80
Chargers Bosch GAL18V40 Bosch GAL18V40
A) The working range may be reduced by unfavorable environmental conditions (e.g. direct sunlight).
B) At 20 °C.
C) Along the axes.
D) At a maximum slope of ±8.5%, the maximum deviation is ±0.2%.
E) Only non-conductive deposits occur, whereby occasional temporary conductivity caused by condensation is
expected.
F) When using Bluetooth® Low Energy devices, it may not be possible to establish a connection depending on the
model and operating system. Bluetooth® devices must support the SPP profile.
G) The signal range may vary greatly depending on external conditions, including the receiving device used. The
Bluetooth® range may be significantly weaker inside closed rooms and through metallic barriers (e.g. walls,
shelving units, cases, etc.).
H) Depends on battery in use.
The serial number (21) on the type plate is used to clearly identify your measuring tool.
GBA18V80
