-34-
Overview of status indicators
Measuring tool Function
Green Red
Ⴝ Horizontal position: X- or Y-axis levelling process.
Vertical position: X-axis levelling process.
Ⴝ Sleep mode activated.
● Horizontal position: Both axes are levelled.
Vertical position: X-axis is levelled.
Ⴝ automatic shut-down due to error message (e.g. empty rechargeable/non-rechargeable battery,
operating temperature exceeded).
Ⴝ Centre line mode started (see operating instructions for the laser receiver).
Ⴝ Position of the measuring tool changed without switching on/off.
Ⴝ Self-levelling not possible, end of the self-levelling range.
Ⴝ Shock-warning function actuated.
Ⴝ Measuring tool is being calibrated.
● Horizontal position: At least one axis is tilted or is in manual operating mode.
Vertical position: X-axis is tilted or in manual operating mode.
●lighting up continuously
Ⴝflashing
Remote control
X
Remote control
Y
Function
Green Red Green Red
Ⴝ X-axis levelling process (horizontal and vertical positions).
Ⴝ Y-axis levelling process (horizontal position).
Ⴝ Ⴝ Remote control is connected via Bluetooth®.
(Both of the status indicators flash alternately.)
Remote control successfully connected via Bluetooth®.
●
●
X-axis is levelled in (horizontal and vertical positions).
●
●
Y-axis is levelled in (horizontal position).
●
●
X-axis is tilted or in manual operating mode (horizontal and vertical
positions).
●
●
Y-axis is tilted or in manual operating mode (horizontal position).
Unsuccessful connection to the measuring tool via Bluetooth®.
●lighting up continuously
Ⴝflashing
