54 A6VM series 71 | Axial piston variable motor
Dimensions size 170
Dimensions [inch (mm)]
▼ HZ5 – Hydraulic two-point control,
negative control
▼ EZ5, EZ6 – Electric two-point control,
negative control
7.76 (197)
4.21 (107)
5.24 (133)
12.71 (323)
14.09 (358)
1.59
(40.5)
X G
G
B A
X
M
1
M
1
M
1
G
B A
M
1
7.76 (197 )
7.36 (187)
14.09 (358)
G
▼ HA1, HA2 / HA1T3, HA2T3 – Automatic high-pressure-related
control, positive control, with override hydraulic remote con-
trolled, proportional
▼ HA1U1, HA2U2 – Automatic high-pressure-related control,
positive control, with override, electric, two-point
1.59
(40.5)
X
G
M
1
G
X
7.13 (181)
B A
M
1
5.24
(133)
7.76 (197 )
13.94 (354)
10.39 (264)
M
1
B A
M
1
G
G
13.94 (354)
5.24(133)
10.47 (266)
HA1 and HA2, X plugged
HA1T and HA2T, X open
▼ HA1R1, HA2R2 – Automatic high-pressure-related control,
positive control, with override, electric and travel direction
valve, electric
a
b
G
M
1
G
B A
M
1
5.24(133)
10.47 (266)
13.94 (354)
4.41
(112)
