Program memory 1 144 Pin SO DIMM 3.3 V PC100, 128 MB
System Core INTEL 440BX AGP Set
Fig.7-3: CPU and memory specification
7.3 PhoenixBIOS Setup
7.3.1 General Information
The BIOS of the NC CPU is a "Phoenix BIOS 4.0 Release 6.8, 256 KByte
FLASH-BIOS, NV-EEPROM". It contains a battery-buffered CMOS memory for
storing date, time and system configuration.
Wrong settings can cause damage to the system or prevent it from
booting.
The BIOS settings of the NC CPU cannot be checked directly at the BTV 20.4A.
If a check of these settings should be necessary, a monitor and a keyboard
have to be directly connected to the NC CPU.
The start and the condition of the BIOS editor are described in chapter 3
7.3.2 PhoenixBIOS settings of the NC CPU
Main
System Time Current time
System Date Current date
Legacy Diskette A 1.44/1.25 MB 3½"
Legacy Diskette B disabled
Primary Master none
Primary Slave none
Secondary Master none
Secondary Slave none
Memory Shadow Submenu
Memory Cache Submenu
System Memory Display of the system memory
Extended Memory Display of the Extended Memory
Fig.7-4: Main menu
Memory Shadow
CC00 - CFFF Disabled
D000 - D3FF Disabled
D400 - D7FF Disabled
D800 - DBFF Disabled
DC00 - DFFF Disabled
Fig.7-5: "Memory Shadow" submenu
84/135 Bosch Rexroth AG | Electric Drives
and Controls
Rexroth MTA 200 | Project Planning Manual
PC CPU Configuration -44
