4.1.19 Display and power modules
Dishwashers can have from one to three controls, depending on
the model: a control module (in the fascia / control panel), a
display module with display, lights & buttons (in the fascia /
control panel) and a power module in the base on the right side.
The power module controls the circulation and drain pumps, while
the control module controls the wash programs.
4.1.20 Sump parts
4.1.20.1 Sump
The sump contains a filter screen, large item (coarse) filter and
micro filter.
The sump holds the drain pump cover and suction cap. The
suction cap, used only with Sicasym circulation pumps, provides
a proper flow rate of water through the sump.
Display module
702_58300000148618_ara_en_a Page 24 of 42
Po
wer module
