Bosch SHX57C User Manual

15
Care and Maintenance EQPVKPWGF
To reinstall the top spray arm:
1. Return the top spray arm to its installed
position.
2. Return the locking nut to its installed
position and turn it 1/8 turn clockwise.
3. Return the top rack to the top rack roller
guides.
To remove the bottom spray arm:
1. Remove the empty bottom rack from the
dishwasher tub.
To reinstall the bottom spray arm:
1. Return the bottom spray arm to its installed
position and press it so that it snaps into
place.
2. Return the bottom rack to its installed
position.
2. Grasp and lift the bottom spray arm as
shown in Figure 33.
3. Look for obstruction in the spray nozzles.
4. +HVJGURTC[PQ\\NGUPGGFENGCPKPIƀWUJ
them under running water.
Check/Clean the Filter System
6JKUFKUJYCUJGTJCUCſNVGTU[UVGOVJCVEQPUKUVU
of a Large Object Trap/Cylinder Filter assembly
and a Fine Filter. Select models have an
CFFKVKQPCN/KETQ(KNVGT6JGſNVGTU[UVGOKUNQECVGF
on the inside of your dishwasher under the lower
rack and is easily accessible.
&WTKPIPQTOCNWUGVJGſNVGTU[UVGOKU
self-cleaning. You should occasionally inspect it
for foreign objects and clean it when necessary.
To Remove the Large Object Trap/Cylinder
Filter Assembly:
1. Remove the bottom rack.
2. Grasp the assembly as shown in Figure 34
and turn it counterclockwise 1/4 turn.
Figure 35
Figure 34
4. Carefully examine the assembly. If you
ſPFFGDTKUKPVJG.CTIG1DLGEV6TCRVWTPKV
upside-down and gently tap it on a surface
such as a countertop to dislodge and remove
the debris. Flush the Cylinder Filter clean by
holding it under running water.
3. Lift out the assembly as shown in Figure 35.
Large
Object
Trap/
Cylinder
Filter
Figure 33
To avoid injury, do not reach into the large
QDLGEVVTCRYKVJ[QWTſPIGTU6JGNCTIG
object trap could contain sharp objects.
CAUTION
