Getting Started en-us
13
The dotted lines show optional
features which may or may not be
included with your dishwasher.
The numbers stated below refer to
the overview images on the previous
page of this manual.
Operating panel
Note: Some of the wash cycles and
options will vary by model.
Dishwasher interior
components
* optional feature which may or may
not be included with your
dishwasher.
Display indicators
--------
( On/Off button
0 Wash cycles
8 Digital display
@ Delay start button
H Wash cycle options
P Start button
1* Third rack *
12 Upper rack
1: Upper spray arm
1B Detergent tab tray
1J Vent hole
1R Lower spray arm
1Z Dispenser for special salt *
1b Filters
1j Silverware basket *
9" Lower rack
9* Rinse aid dispenser
92 Detergent dispenser
9: Lock for detergent dispenser
9B Rating plate
‹:‹‹
Cycle time remaining
Clean
Lights up when dishes are
clean
Sanitize
Lights up when sanitation
requirements are met
Add Rinse
Aid
Lights up when rinse aid is low
