-10-
Functional Description and Specifications
CANISTER
HOSE PORT
POWER TOOL
OUTLET
MODE SELECTOR
SWITCH
CANISTER LATCH
REAR WHEEL
CASTER BRAKE
CASTER
FIG. 3
POWER BROKER DIAL
AUTOMATIC FILTER
CLEANING BUTTON
CASTER FRAME
(VAC140 ONLY)
CORD HOOK
PUSH HANDLE
(VAC140 ONLY)
CARRYING
HANDLE
L-BOXX
RETAINER
Automatic Filter Cleaning Dust Extractor
(VAC090A & VAC140A)
* 14 gallon canister shown. See page 8 for 9 gallon canister
