Bosch WKD28540EE - Page 25

25
Levelling
Intense noise, vibrations and “wandering” may be the result of incorrect
levelling.
– All four appliance feet must stand firmly on the ground.
– The washer-dryer must not wobble.
– Check the levelness of the washer-dryer with a spirit level and correct
if necessary.
– The washer-dryer must not rest against the sides of the installation
recess.
– The lock nuts of the front appliance feet must be screwed tightly
against the housing.
.
Hose and cable lengths
Left-hand connection
or
Right-hand connection
Dimensions
Width x depth x height 595 mm x 584 mm x 820 mm
Weight 85 kg
Dimensions in mm
min.
500
max.
900
approx. 1400
approx. 1400
approx. 1350
approx. 950
approx. 1000
approx.
760
min.
500
max.
900
