7
Programme overview also see Page 5
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.
After drying...
c
iron laundry
lightly iron laundry
@c
do not iron laundry
c
mangle laundry
PROGRAMMES TEXTILE TYPE AND INFORMATION
**L Cottons
max. 7 kg
Hard-wearing fabrics, bo il-resistant fabrics made of cotton or linen.
**IEasy-Care
max. 3.5 kg Non-iro n laundry made of synthetic fibres and blended f abric, easy-care cotton.
Iron Dry c÷@c
Fabrics suitable for ironin g (iron fabrics in order to avoid creasing).
Cupboard Dry
@
Single-layer fabrics.
*Extra Dry
@
Fabrics made of thick, multila yered items of clothing.
ZSportswear
max. 1.5 kg
Fabrics with membrane c oating, water-repellent fabrics, functional c lothing, fleece fabrics (dry jackets/trousers with
removable internal lining s eparately).
A SuperQuick 40
max. 2 kg
Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may
differ from the those specifie d depending on the type of fabric, mixture of laun dry to be dried, residual moisture in the
fabric and loading capacit y.
Timed Programme
warm 20 min.
max. 3 kg
Pre-dried, multi-layered, sens itive fabrics made of acrylic fibres, or sepa rate small items of laundry.
Also for subsequent drying .
*for LCottons and IEasy-C are programmes only
**Dryness levels can be selected individually aExtra Dry, Cupboard Dry and Iron Dry (depending on the model).
Degree of dryness can be finely adjusted; mult i-layered textiles require a longer drying time than single-layered items of clothing . Recommendation: Dry separately.
9303 / 9000874932
*874932*
Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München/Deutschland
WTE84106GB
8
Installation
Delivery specification: drye r, instructions for installation and use, wool lens basket
(depending on model).
Check dryer for transport d amage.
The dryer is very heavy. D o not attempt to lift it on your own.
Be careful to avoid sharp e dges.
Do not lift the dryer by any of the protruding parts (e.g. the d oor) as they may break off.
Do not set up in a room th at is susceptible to frost.
Freezing water may cause damage.
If in doubt, have the appliance connected by an expert.
Setting up the dryer
The appliance plug mus t always be accessible.
Ensure that the appliance is installed on a clean, level
and solid surface.
Keep the cooling grille at t he front of the dryer
unobstructed.
Keep the area around the dryer clean.
Make the dryer level usin g the threaded feet
and a spirit level.
Do not remove the threaded feet un der any
circumstances.
Mains connection see safety instructions
a
Page 11.
Connect to an AC earthed s ocket. If in doubt have the socket che cked by an expert.
The mains voltage and the voltage shown on the rating plate (
a
Page 9) must correspond.
The connected load and necessary fuse protection are specified o n the rating plate.
Frost protection / Transport
Preparation
1. Empty the condensation container
a
page 4.
2. Select any programm e using the programme s elector.
3. Press the
Start/Stop button
a
condensation is pum ped into the container.
4. Wait 5 min., and then empty the condensat ion container again.
5. Turn the programme s elector to Off.
Take all accessory parts
out of the drum.
The drum must be empty.
Make sure that the air
inlet remains unobstructed
Clean and level
Do not operate the dryer if
there is a danger of fro st.
Do not set up the dryer behind a door or sliding
door as this may obstruct or prevent the dryer door
from opening. This will prevent a potentiall y fatal
danger to children from locking thems elves in.
9
Technical data
ʠ
Dimensions (DxWxH) 60 x 60 x 85 cm (height adjustable)
Weight approximately 45 kg
Max. capacity 7 kg
Condensation container 4.2 l
Connection voltage
Connected load
Fuse protection see appliance ratin g plate
Ambient temperature
Product number/
Production number
You can find the rating plate on th e back of the dryer.
ʠ
Drum interior light (depend ing on model) (bulb E14, 2 5 W)
The drum lights up after t he door is opened or closed, an d after the programme star ts,
and switches off automatica lly. Changing the bulb apa ge 10.
Consumption rates
Fabrics/programmes
Residual moisture in the fabrics
after spinning
Drying time**
Energy
consumption**
L Cottons 7 kg
Cupboard Dry* 1400 rpm (50%) 106 min 3.60 kWh
1000 rpm (60%) 124 min 4.20 kWh
800 rpm (70%) 143 min 4.80 kWh
Iron Dry* 1400 rpm (50%) 82 min 2.59 kWh
1000 rpm (60%) 98 min 3.28 kWh
800 rpm (70%) 112 min 3.96 kWh
cEasy-Care 3.5 kg
Cupboard Dry* 800 rpm (40%) 42 min 1.35 kWh
600 rpm (50%) 51 min 1.65 kWh
* Programm e setting for testing in accordance with applicable standard EN61121.
** The values may differ from those specified, depending on the type o f fabric, composition of
laundry to be dried, residual moisture in the fabric and the amount of laundry be ing loaded.
Fabrics/programmes Drying time Annual energy consumption
L Cottons 7 kg / 3.5 kg*
Cupboard Dry*** 97 min / per cycle 504 kWh / per year
***Programme s etting for testing and energy labelling in ac cordance with Directive 2010/30/EU .
Optional accessories (f rom after-sales service using order num ber)
Platform
For easier loading and unloading. The bask et contained in the drawer can be used to carry
the laundry.
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space. The dryer must be fastened to the washing machine using this connection set.
With pull-out worktop: WTZ 11300
Connection fittings for conden sation outlet
The condensation is conveyed direc tly via a hose.
Installation underneath the worktop
Instead of the appliance covering p late, you must have a metal cover fitted by
a specialist.
10
What to do if ...
If you cannot rectify a fault yourself (e.g. sw itching off/on), please contact our after-sales
service. We will alw ays find an appropri ate solution and will avoid unnecessary visits by
engineers. Trust t he expertise of the manufa cturer and rest assu red that the repair will b e
carried out by trained service technicians using original spare parts. The contact details of your
local after-sales serv ice can be found in th e enclosed after-sales service dire ctory, or by
calling one of these n umbers:
GB 0844 8928979 (Calls from a BT landline will be charg ed at up to 3 pence p er minute.
A call set-u p fee of up t o 6 pence m ay apply.)
IE 01450 2655
When contacting the after- sales service, please quote the applia nce's product number (E no.)
and production nu mber (FD) (see the inside of the door).
Set the programm e selector to
Off and remove the app liance plug from the socket.
ʠ
The Start/Stop indicator lamp
does not light up.
Mains plug plugged in?
Programme selected?
Check the socket fuse.
ʠ
The display panel light and
indicator lights (depending on
model) go out and the
Start/
Stop indicator light flashe s.
Energy-saving mode is activated
a
see the separate Energy-s aving mode instructions.
ʠ
The Container and
Start/Stop indicator lights are
flashing.
Empty the condensation c ontainer.
If featured, check hose for condensation outlet.
ʠ
The Clean and Start/Stop
indicator lights are flashing.
Clean the fluff filter and/or air cool er under running water
a
Page 4/6.
ʠ
Dryer does not start.
Start/Stop button selected?
Door closed?
Programme set?
Ambient temperature gre ater than 5 °C?
ʠ
Water is running out. Align dryer horizontally.
Clean air cooler seal.
ʠ
The door opens by itself. Push the door closed until you hear it engage.
ʠ
Creasing. Laundry load exceeded?
Remove articles of clothin g immediately after
the end of the programme , hang up and pull into shape.
Unsuitable programme sel ected a Page 7.
ʠ
Drying result is not satisfacto ry
(laundry feels too damp).
Warm laundry feels damp er than it actually is.
The selected program me does not suit the load. Use another
drying programme or, in addition, select the time prog ramme a
Page 7.
Use fine adjustment for the drying result aPage 5/6.
Fine layer of limescale on the humidity sensors
a Clean the humidity sen sors aPage 6.
Programme termination, e.g. tank full, mains power supply failure,
door open or maximum dryi ng time reached.
ʠ
Drying time too long. Rinse the fluff filters under running wa ter a Page 4.
Insufficient supply of air a ensu re that air can circulate.
Air inlet possibly blocked a Clear inlet aPage 8.
Ambient temperature h igher than 35 °C a ventilate the room.
ʠ
The humidity in the room
increases significantly.
Make sure the room is sufficiently ventilated.
ʠ
Mains failure. Remove laundry from t he dryer immediately and spr ead out.
This allows the heat to di ssipate.
ʠ
One or more indicator li ghts for
programme status are fl ashing.
Clean filter and air coole r
a
Page 4/6.
Check installation condi tions
a
Page 8.
Switch off, leave to cool do wn, switch on again, restart
programme.
ʠ
The interior light is not wo rking
(depending on model).
Pull out the appliance pl ug, remove the cover cap in the interior
above the door (use Torx 20 sc rew driver) and replace
the bulb. Close the cover ca p.
Never operate the dryer without a cover cap.
11
Safety instructions
Emergency
Pull the appliance plug out of the socket immedia tely or disconnect the fuse.
ONLY use the
dryer...
in rooms inside the hou se.
to dry fabrics.
The dryer must
NEVER...
be used for other purp oses than those described above.
be modified in terms of its technology or attributes.
Dangers
The dryer must not be used by children or persons who have n ot been
instructed in its use.
Do not leave children u nsupervised near the dryer.
Keep pets away from th e dryer.
Remove all objects from pockets.
Make especially sure that cigare tte lighters are removed as they constit ute
an
a
explosion hazard.
Do not lean or sit on the do or
a
risk of tipping.
Installation
Secure loose cables
a
tripping hazard.
Do not operate the dr yer if there is a risk of frost.
Mains
connection
Connect the dryer acc ording to specifications to an AC earthe d socket, as
otherwise it cannot be guarante ed that the appliance is completely safe.
The cable cross-secti on must be sufficient.
Only use earth-leakage circuit breakers with the following symb ol:
The appliance plug a nd socket must be compatible.
Do not use multiple plugs /couplings and/or extension cables.
Do not hold the applia nce plug with wet hands
a
risk of electric shock.
Never pull the applianc e plug out of the socket by its cable.
Do not damage the main s lead
a
risk of electric shock.
Operation
Only load the drum with laundry.
Check the contents before you swi tch the dryer on.
Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair setting s pray, nail polish remover, stain remover,
cleaning solvent, etc.)
a
fire/explosion hazard.
Dust (e.g. coal dust, flour) poses a danger: do not use the dryer
a
explosion hazard.
Do not put laundry containing foamed material/rubber in the dryer
a
elastic
material may be destroyed and the dryer may be damaged due to possi ble
deformation of the foamed mat erial.
Switch off the dryer once the programme has ended.
Condensation is not dri nking water and may be contaminated wit h fluff.
Defect
Do not use the dryer if it is defective or if you suspect it is.
Repairs must only be carried o ut by the after-sales service.
Do not use the dryer if th e mains cable is defective. To avoid d anger, only
have the defective mains cabl e replaced by the after-sales service.
Always pull the mains plug out of the socket before changing the bulb for the
interior light
a
risk of electric shock.
Spare parts
Only use genuine spar e parts and accessories for safety reas ons.
Disposal
Dryer: pull out the appl iance plug, then cut off the main s cable from
the appliance.
Dispose of at municipal waste d isposal facility.
Packaging: do not leav e children alone with packing parts
a
risk of suffocation.
All materials are environm entally sound and can be reused . Dispose of in
an environmentally-responsible manner.
Dryer
en Instruc tion manual
To Next Page
Loading...
Need help?
General
