8
Installation
– Scope of delivery: dryer, installation and operating instructions.
– Check dryer for transport damag e.
– The dryer is very heavy. Do not at tempt to lift it on your own.
– Be careful to avoid sharp edge s.
– Do not set up in a room that is susceptible to frost. Freezing water may cau se damage.
– If in doubt, have the appliance connected by a specialist.
– Do not lift the dryer by protruding p arts (e.g. the door) - risk of breakage.
Setting up the d ryer
– The appliance plug must alwa ys be accessible.
– Ensure that the appliance is installed on a clean, level
and firm surface.
– Do not obstruct the air inlet on the front of the
dryer.
– Keep the area around the dryer clean.
– Make the dryer level using the th readed feet
and a spirit level.
– Do not remove the threaded fee t under any
circumstances.
Mains connect ion see Safety instructions a page 13.
– Connect to an AC earthed socket. If in doubt have the socket checked by a s pecialist.
– The mains voltage and the volta ge shown on the rating plate (apage 10) must be the
same.
– The connected load and nece ssary fuse protection are specified on the rating plate.
Frost protection
Preparation
1. Empty the condensation containe r apage 4.
2. Select any programme using the progra mme selector.
3. Press the Ĕ Start/Stop button a condensed water is pumped into the container
4. Wait 5 minutes and then empty the condensation container again.
5. Turn the programme selector to Off.
Transport
– Prepare the dryer a see Frost protection.
– Transport the dryer in a vertical up right position.
– Following transportation, do not us e the dryer for two hours.
The dryer contains residual water;
this can flow out if the dryer is tilted.
Take all accessory parts out
of the drum.
The drum must be empty.
Make sure that the air inlet
remains unobstructed
Clean and level
Do not set up the dryer behind a door or sliding
door, as this may obstruct the dryer door or prevent
it from opening. This will prevent a potentially fat al
danger to children from locking themselves in.
Do not operate the dryer if
there is a danger of frost.
9
Care and cleaning
Heat exchanger
The dryer's heat exchanger is cleaned automa tically during drying. Cln appears in the display
panel. Do not pull out the condens ation container during the cleaning proces s.
Dryer housing , control panel, a ir intake
Wipe with a soft, damp cloth.
Do not use harsh cleaning agents or solve nts.
Remove detergent and cleaning agent residue immediately.
Some water may collect between th e window and the seal during drying. Thi s does not affect
the proper operation of your dryer in any way.
Filter in the conde nsation contai ner
The filter is cleaned automatically wh en the condensation container is emptied.
However, the filter should still be cleaned regularly under running water a This prevents
stubborn deposits/dirt from building up.
1. Pull out the condensation container.
2. Pull the filter out of its snap-in lock.
3. Clean the filter under running water or in the dishwasher.
4. Refit the filter.
5. Insert the condensation container so that it locks into place.
Only operate the dryer with the filter inserted.
Moisture senso r
The dryer is equipped with stainless steel moisture sensors. Moisture sensors measure how
damp the laundry is. A thin layer of limescale ma y build up on the moistu re sensors after
prolonged use.
1. Open the door.
2. Clean the moisture sensors using a damp sponge with a rough surface.
Do not use steel wool or abrasive mater ials.
Appliance must be switched off.
10
Technical data
ʠ
Dimensions (DxWxH) 60 x 60 x 85 cm (h eight adjustable)
Weight approximately 51 kg
Max. capacity 7 kg
Condensation container 4.0 l
Connection voltage 220-240 V
Connected load max. 1000 W
Fuse protection 10 A
Ambient temperature 5 - 35 °C
Product number
Production number
under the door
The rating plate can be found on the ba ck of the dryer.
ʠ
Consumption ra tes
These are guide values determined under standard
conditions.
Spin speed
in rpm
(residual moisture)
Drying time
in min.**
Energy
consumption
in kWh**
Cottons 7 kg
Cupboard Dry* 1400 (approx. 50 %) 128 1.62
1000 (approx. 60 %) 149 1.90
800 (approx. 70 %) 169 2.19
Iron Dry* 1400 (approx. 50 %) 92 1.13
1000 (approx. 60 %) 113 1.42
800 (approx. 70 %) 133 1.70
#÷Easy-Care 3.5 kg
Cupboard Dry* 800 (approx. 40 %) 54 0.57
600 (approx. 50 %) 68 0.72
*Test programs according to DIN EN 61121
**The values may differ from those given, de pending on overvoltage and undervoltage, the
type of fabric, composition of the laundry to be dried, the residual moisture in the fabric and
the size of the load.
ʠ
Drum interior ligh t (depending on model) (bulb E14, 25 W)
The drum lights up after the door is opened or closed, and after the programme starts, and
switches off automatically. Changing the bulb apage 12.
Optional accessories (from after -sales service using order number)
Washer-dryer stack con nection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space. The dryer must be fastened to the washing machine using this connection set.
Same as WTZ 11310, but with pull-out wor ktop.
Installation unde rneath the worktop
Instead of the appliance covering plate, y ou must have a metal cover fitted by a spec ialist.
11
Normal noises
During drying, the compressor and th e pump generate some noise which is entirely n ormal.
The compressor in the dryer may
occasionally generate a humming noise.
The compressor in the dryer is ventilated
from time to time, which creates a whirring
sound.
The automatic cleaning process causes
a clicking noise.
The process of pumping the condensation
into the condensation container generates
pumping noises.
12
What to do if...
If you cannot rectify a fa ult yourself (e.g. switchin g off/on), please contact o ur after-sales
service. We will alway s find an appropriate sol ution and will avoid unnecessar y visits by
engineers. Trust the exp ertise of the manufacture r and rest assured that th e repair will be
carried out by trained service technicians using original spare parts. The contact details of your
local after-sales service can be found in the enclosed after-sales service directory, or by calling
one of these numbers:
– GB 0844 8928979 (Calls from a BT landline will be charged at up to 3 pence per minute.
A call set-up fee of up to 6 pence may a pply.)
– IE 01450 2655
When contacting the after-sale s service, please quote the appliance's product num ber (E no.)
and production numbe r (FD) (see under the lo ading door).
Turn the programme selector to Off and unplug the m ains plug from the socket.
ʠ
The ĔStart /Stop indicator lamp
does not light up.
Mains plug p lugged in?
Programme s elected?
ʠ
The Contain er indicator lamp
and the ĔSt art/Stop button are
flashing.
Empty the co ndensation container apage 4 .
Clean the con densation con tainer filter if necessary
apage 9.
Dryer transpo rted? a Wait 2 hours and star t again.
ʠ
The Filter indic ator lamp and
ĔStart /Stop button are flashing.
Rinse the flu ff filter under ru nning water apage 4.
ʠ
Cln appears in the display panel . N ot an error. Au tomatic clea ning of the he at exchanger.
Do not emp ty the condens ation contain er.
ʠ
Dryer does n ot start. Ĕ Start/S top button selec ted?
Door closed? Programme set?
Ambient temp erature grea ter than 5 °C?
ʠ
Water is leak ing out. Make sure the dryer is lev el.
ʠ
The door open s by itself. Push the door closed until you hear it clic k into place .
ʠ
Creasing. Laundry load exceeded?
Remove articles of clothing immediately after the end of the
programme, hang up and pull into shap e.
Unsuitable p rogramme se lected a page 7 .
ʠ
Drying result is not satisfac tory
(laundry feel s too damp).
Warm laund ry feels dampe r than it actu ally is.
The selecte d programme does not suit the load. Use
another drying programme or, in addition , select the time
programme apage 7.
Use fine adjustment for the drying result a page 1/2 and 6.
Fine layer of limescale on the humidity sensors
a Clean the h umidity sens ors apage 9.
Programme t ermination, e.g. tank full, mains power supply
failure, door open or max imum drying time reached.
ʠ
Drying time too long. Rinse the fluff filters under runnin g water a pa ge 4.
Insufficient s upply of air a e nsure that air c an circulate.
Air inlet possib ly blocked a Clear inlet apa ge 8.
Ambient temp erature hig her than 35 °C a ventilate the
room.
ʠ
The humidit y in the room
increases sign ificantly.
Make sure the room is su fficiently ventila ted.
ʠ
Power failure . Remove laundry from the dryer immediatel y and spread out.
This allows th e heat to diss ipate.
ʠ
Other interm ittent noises
and vibration s.
Not an error.
Normal noise s apage 11.
ʠ
Loud humming noise for several
seconds.
Has the cond ensation con tainer been p roperly inserted ?
a Push the con densation con tainer all th e way in.
Not an error. Normal noise s apage 11.
ʠ
The interior lig ht is not work ing
(depending o n model).
Pull out the a ppliance plug , remove the cover cap in the
interior above the door (us e Torx 20 screw driver) and
replace the bulb apage 10. Close the cov er cap.
Never operate the dryer wit hout a cover cap.
13
Safety instructions
Emergency
– Pull the applian ce plug out of the socke t immediately or disconne ct the fuse.
ONLY use the
dryer...
– in rooms insid e the house.
– to dry fabrics.
The dryer must
NEVER...
– be used for pur poses other than those d escribed above.
– be modified in terms of its technology or p roperties.
Hazards
– The dryer mus t not be used by childre n or persons who have not be en
instructed in its use.
– Do not leave c hildren unsupervised n ear the dryer.
– Keep pets away from the dryer.
– Remove all obje cts from pockets,
and lighters in particular a Risk of explosion.
– Do not lean or sit on the door a Risk o f tipping.
Installation
– Secure loos e cables a Risk of tr ipping.
– Do not oper ate a dryer if there is a risk of frost.
Mains
connection
– Connect the dryer to an AC earthed so cket according to specificat ions,
otherwise it cannot be gua ranteed that the app liance is completely safe.
– The cable cross-section must be su fficient.
– Only use ea rth-leakage circuit breake rs with the following symbol:
– The appliance plug and socket must b e compatible.
– Do not use mult iple plugs/connectors and/or extension cables.
– Do not touch or hold the appliance plug with wet hands
a Risk of electric shock .
– Never pull the appliance plug out of the socket by its cable.
– Do not dam age the mains lead a Risk of electric shock.
Operation
– Only load the drum with laundry.
Check the contents be fore you switch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair styling products, nail varnish remover, stain remover,
cleaning solvent, etc.) a Risk of fire/explosion.
– Dust (e.g. co al dust, flour) poses a danger: Do not use the dryer
aRisk of explosion
– Do not put laund ry containing foamed m aterial/rubber in the dryer a elastic
material may be destro yed and the dryer be dam aged due to possible
deformation of the foam ed material.
– When cleaning the fluff filter, make sure that no foreign material (down or filling
material) gets into the air duct opening. If necessary, clean the drum
beforehand with a vacuu m cleaner. If foreign mate rial should still get into the
air duct a call the after- sales service a Risk of fire/explosion.
– Switch off the d ryer once the programme has ended.
– The water from condensation is not drink ing water and may be co ntaminated
with fluff.
Defect
– Do not use the dryer if it is defective or if you suspect that it is.
Repairs must only be carrie d out by the after-sales service.
– Do not use the dryer if the mains cable is defective. To avoid danger, only have
the defective mains cable replaced by the after-s ales service.
– Always pull t he mains plug out of the sock et before changing the bulb for the
interior light a Ri sk of electric shock.
Spare parts
– Only use genu ine spare parts and acc essories for safety reasons.
Disposal
– Pull out the app liance plug, then cut off the mains cable from the appliance.
Dispose of at a municipa l waste disposal facility.
– Heat exchang ers contain a fluorinated greenhouse gas covered by the Kyoto
protocol (R134a) a disp ose of in a proper manne r. Capacity: 0.22 kg.
– Packaging: Keep all packaging out of reach of babies and childre n
a Risk of suffocation.
– All materials are environmentally soun d and can be reused. Dis pose of in an
environmentally-responsibl e manner.
Dryer
en Instruct ion manual
To Next Page
Loading...
