Functional Description
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Intended Use
The machine is intended for cutting flexible, soft materials of up
to 6 mm in thickness, such as carpet, PVC, cardboard, leather,
fabrics and similar materials.
Product Features
The numbering of the components shown refers to the represen-
tation of the power tool on the graphic pages.
1 On/Off switch
2 Lock-off button for On/Off switch
3 Blade guard
4 Blade
5 Guide edge
6 “Cut Control” cutting-line mark
7 Battery charge-control indicator
8 Handle
9 Socket for charge plug
10 Plug connector for charger
11 Charge cradle for battery*
12 Blade screw
13 Cutting adapter*
*Accessories shown or described are not part of the standard delivery
scope of the product. A complete overview of accessories can be found in
our accessories program.
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted sound pressure level of the product is
less than 70 dB(A). Uncertainty K =3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Vibration total values (triax vector sum) determined according to
EN 60745:
Vibration emission value a
h
<2.5 m/s
2
, Uncertainty K =1.5 m/s
2
.
