Bose 1800-V - Page 32

32
4.2 802 High Frequency Response
IMPORTANT: Set the Input Module's S2 switch to the HF Only (High Frequency) position before
beginning this test.
FREQUENCY OUTPUT SPECIFICATION (dbr)
40 -21.0±1.5 dB
60 -11.5±1.5 dB
700 0.0
2500 +2.1±1.5dB
6000 +9.6±1.5dB
14500 +16.7±1.5dB
