AV20/35 Main PCB Part List
Resistors
Capacitors
Reference
Desi
g
nator
Description Material Number Note
R16008 121K, 0603, .1W, 1% 19146
5
-1213
R16011 1.05K, 0603, .1W, 1% 191465-1051
R16012 196 OHMS, 0603, .1W, 1% 191465-1960
R16013 2.0K, 0603, .1W, 5% 199403-202
R16014 0.10 OHM, 0805, 1/8W, 5% 304926-R10
R17000 2.2K, 0603, .1W, 5% 199403-222
R17001 3.3K, 0603, .1W, 5%, 199403-332
R17003 10 OHM, 0603, .1W, 1% 191465-10R0
R17005 6.49 K, 0603, .1W, 1% 191465-6491
R17006 475 OHM, 0603, .1W, 1% 19146
5
-4750
R17007 1K, 0603, .1W, 1% 19146
5
-1001
R17008 4.70K, 0603, .1W, 1% 19146
5
-4701
R17010 7.5K, 0603, .1W, 1% 19146
5
-7501
R17011 4.7 OHM, 0603, .1W, 5% 199403-4R7
R17012 4.7 OHM, 0603, .1W, 5% 199403-4R7
R17013 4.7 OHM, 0603, .1W, 5% 199403-4R7
R17014 4.70K, 0603, .1W, 1% 191465-4701
R17015 4.22K, 0603, .1W, 1% 191465-4221
R17016 4.70K, 0603, .1W, 1% 191465-4701
R17017 1.62K, 0603, .1W, 1% 191465-1621
R17018 4.70K, 0603, .1W, 1% 191465-4701
R17019 10K, 0603, .1W, 1% 19146
5
-1002
R17020 10 OHM, 0603, .1W, 5% 199403-100
R17021 10 OHM, 0603, .1W, 5% 199403-100
R17022 10 OHM, 0603, .1W, 5% 199403-100
R17023 2.49K, 0603, .1W, 1% 19146
5
-2491
R17024 2.49K, 0603, .1W, 1% 19146
5
-2491
R17025 2.49K, 0603, .1W, 1% 191465-2491
Reference
Desi
g
nator
Description Material Number Note
C1000 0.10uF, 0603, 16V, 5% 258498-104
C1001 0.10uF, 0603, 16V, 5% 258498-104
C1002 0.10uF, 0603, 16V, 5% 258498-104
C1003 1000PF, 0603, COG, 50V, 5% 188454-102
C1006 100uF, EL, SMD, 105, 16V, 20% 306169-101CF
C1009 0.10uF, 0603, 16V, 5% 258498-104
AV35
C1010 0.10uF, 0603, 16V, 5% 258498-104
AV35
C1011 0.10uF, 0603, 16V, 5% 258498-104
A
V35

