Part List Notes
1. This part is not normally available from customer service. Approval from the Field Service Manager
is required before ordering.
2. The individual parts located on the PCB are listed in the part list.
3. This part is critical for safety purposes. Failure to use a substitute replacement with the
same safety characteristics as the recommended replacement part might create shock, fire and/or
other hazards.
4. This part is referenced for informational purposes only. It is not stocked as a repair part. Refer
to the next higher or lower level assembly for a replacement part.
5. When replacing the tuner PCB in the AV35 console, use the table below to identify the console type.
The difference between the two PCB types is the Apple authentication chip used, U103. To comply with
Apple licence agreements, the appropriate PCB must be used. WWiP = Works With iPhone.
6. Refer to the console variant list on page 6. Use the appropriate replacement console for the
customer’s system and country variant.
7. When replacing the Main PCB for Non-US units, the console variant needs to be set to show the
proper language selection. Refer to page 67 Setting the Console’s Product, Region Variant
8. When replacing a PCB in a AVM console, refer to page 6 to varify console type. Use PCBs with IP
(iPhone) in the description for consoles sold with the VideoWave
®
II system.
First 6 digits of
serial number
Country
Variant
WWiP
Tuner PCB
Non-WWiP
Tuner PCB
051115 US X
051526 EURO X
051527 JAPAN X
053582 AP X
054581 US X
054582 EURO X
054583 JAPAN X
054584 AP X
First 6 digits of
serial number
Country
V
ariant
IP PCB
s
(
VideoWav
e
®
I
I
)
Non-IP PCBs
(
VideoWave
)
051528 US X
053791 EURO X
053792 JAPAN X
053793 A
P
X
057508 US X
057509 EURO X
057510 JAPAN X
057521 A
P
X
