11
Figure 2. L1 Model 1S Line Array Packaging View
L1
®
Model 1S Line Array (see Figure 2)
Packaging Part List
Item
Number
Description Part Number Qty. Note
1 Carton Sheet 374346-0010 2
2 PE Foam, Side 355204-0010 4
3 PE Foam, Middle 355205-0010 2
4 Carton 355165-0010 1
5 L1.5 Array Extension (Lower Section) REF 1
6 Poly Bag, Line Array - 1 4
7 L1.5 Line Array (Upper Section) REF 1
8 Carry Bag, Line Array 354530-0110 1
