Main Part List
L1
®
Model 1S Power Stand Upper Housing (see Figure 6)
Item
Number
Description Part Number Qty. Note
1 HOUSING, UPPER (PLASTIC HOUSING ONLY) 298051 1
2 SWITCH, AC POWER, ROCKER, 2P1T 304984 1 3
3 SCREW, M3X12, CSH, BK - 2 4
4 SCREW, M3X12, CSH, BK - 2 4
5 SCREW, B-TITE, FLAT-CS, M3X10, BZ - 2 4
6 I/O PANEL COVER, US/CAN
I/O PANEL COVER, EU/AUS
354557-0110
354941-0110
1
1
7 SCREW, M4X12, PH, BK - 6 4
8 LED LIGHTPIPE #2 298381 1
9 LED LIGHTPIPE #1 298380 1
10 AC POWER SOCKET 304131 1 3
11 BRACKET, AC INLET 298383 1
12 AC PRIMARY PCB ASSEMBLY 304983 1 2
13 I/O-DSP PCB ASSY, SERVICE 355471-001S 1 2
14 SHIELD, COVER - 1
15 SCREW, B-TITE, BIND, M3X8 - 8 4
16 SCREW, 3*8, 5.2MM, BK, ZINC - 2 4
17 WASHER, METAL, ID 3.3, OD 8, T=0.5 - 2 4
18 HANDLE 298054 1
19 SCREW, D3X5, B-TITE, YEL ZN - 2 4
20 FAN GRILLE 298058 1
21 SCREW, MACHINE, FLAT-CS, M3X6, BZ - 3 4
22 PCB BRACKET 298067 1
23 FAN BRACKET - 1 4
24 SCREW, M4X6, P/M, BLK - 4 4
25 FAN, DC, 12V, 5500 RPM See service
bulletin
296133-B1
2 3
26 SCREW, MACHINE, M3X12, B/H, BLACK, ZINC - 4 4
27 PCB SHIELD SHEET - 1
28 MICA INSULATING SHEET 304986 2
29 HEAT SINK, PCB BRACKET 298073 2
30 SMPS/PWR AMP PCB ASSY
US/CANADA
EURO/AUS
358960-111S
358961-211S
2
2
2
31 SCREW, MACHINE, M3X5, BH, Y-ZINC - 14 4
32 KNOB, VR 298382 1
