Bose L1 1S User Manual

17
Main Part List
L1
®
Model 1S Power Stand Cavity and Leg Assembly (see Figure 7)
Item
Number
Description Part Number Qty. Note
LEG ASSEMBLY, INCLUDES: 361795-001S 1
1 LEG-1 - 2 4
2 FOOT - 4 4
3 WASHER, METAL, M4X0.8X10 - 4 4
4 SCREW, M4X12, PH, BK - 4 4
5 LEG-2 - 2 4
6 LOWER LEG BEARING - 4 4
7 SCREW, MACHINE, FLAT-CS, M3X6, BZ - 16 4
8 SCREW, MACHINE, 4*6, 6.8MM, BK, CR HD - 16 4
9 SCREW, MACHINE, FLAT-CS, M4X12, BZ - 2 4
10 BOTTOM COVER - 1 4
11 BEARING SUPPORT - 4 4
12 UPPER LEG BEARING - 4 4
13 SCREW, FLAT-CS, M3X5MM, BZ - 12 4
14 CROSS BEAM - 2 4
15 SCREW, M4X6, P/M, BLK - 4 4
16 LINE ARRAY CONNECTOR / CABLE HARNESS 355488-001S 1
17 CAVITY, LINE ARRAY - 1 4
18 SCREW, MACHINE, 4*5, 6MM, BLK, CROSS RCS - 4 4
19 LINKAG E MOTHER PLATE - 1 4
20 GUIDE MOTHER PLATE - 1 4
21 SCREW, MACH, PAN, M3X8, BZ - 6 4
22 GUIDE SHAFT, BLACK - 2 4
23 CAVITY STO
P
298069 1
24 BEARING PLATE #1 - 2 4
25 SCREW, FLAT-CS, M6X14, BZ - 8 4
26 BEARING PLATE #2 - 2 4
27 FRONT LINK - 2 4
28 REAR LINK - 2 4
29 LINK BEARING - 8 4
30 LINK BEARING WASHE
R
- 8 4
31 METAL WASHER - 8 4
32 SPRING WASHER - 8 4
33 NUT, HEX, 6MMX5.0T, BK, ZN - 8 4
34 EMI GASKET, SHIELDING - 4 4
