Bose L1 1S User Manual

33
Electrical Part List
Capacitors (continued)
Input/Output and DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C307 1000pF, CC, 50V, 10%, 0603, X7
R
150F-102KAC 4
C308 1000
p
F, CC, 50V, 10%, 0603, X7
R
150F-102KAC 4
C309 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C310 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C311 1000pF, CC, 50V, 10%, 0603, X7
R
150F-102KAC 4
C312 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C313 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C314 0.01uF, CC, 50V, 10%, 0603, X7R 150F-103KAC 4
C315 0.01uF, CC, 50V, 10%, 0603, X7
R
150F-103KAC 4
C316 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C317 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C318 0.1uF, CC, 50V, 10%, 0603, X7R 150F-104KAC 4
C319 0.1uF, CC, 50V, 10%, 0603, X7
R
150F-104KAC 4
C320 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C321 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C322 0.01uF, CC, 50V, 10%, 0603, X7
R
150F-103KAC 4
C323 0.01uF, CC, 50V, 10%, 0603, X7R 150F-103KAC 4
C324 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C325 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C326 100uF, CE, 35V, 20%, RLT, 6.3X11, 105C, LOW
ESR
157Q-
107MLUTR
4
C327 100uF, CE, 35V, 20%, RLT, 6.3X11, 105C, LOW
ESR
157Q-
107MLUTR
4
C328 1000pF, CC, 50V, 10%, 0603, X7
R
150F-102KAC 4
C329 220uF, CE, 35V, 20%, RLT, 8X11.5, 105C, LOW
ESR
157Q-
227MOVTR
4
C330 0.1uF, CC, 50V, 10%, 0603, X7R 150F-104KAC 4
C331 0.01uF, CC, 50V, 10%, 0603, X7R 150F-103KAC 4
C332 2200pF, CC, 50V, 10%, 0603, X7R 150F-272KAC 4
C334 0.1uF, CC, 50V, 10%, 0603, X7
R
150F-104KAC 4
C335 47uF, CT, 16V, 10%, SMD, 85C 154D-476KKF 4
C336 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C337 0.01uF, CC, 50V, 10%, 0603, X7R 150F-103KAC 4
C338 0.1uF, CC, 50V, 10%, 0603, X7
R
150F-104KAC 4
C339 1uF, CC, 16V, 10%, 0603, 0.8X1.6 150D-105KAC 4
C340 0.1uF, CC, 50V, 10%, 0603, X7R 150F-104KAC 4
C341 0.1uF, CC, 50V, 10%, 0603, X7R 150F-104KAC 4
C342 100uF, CT, 10V, 20%, SMD, 3.2X6.0 154C-107MFK 4
C343 0.01uF, CC, 50V, 10%, 0603, X7R 150F-103KAC 4
C344 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C346 1000pF, CC, 50V, 10%, 0603, X7
R
150F-102KAC 4
C347 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C348 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C349 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C352 1000
p
F, CC, 50V, 10%, 0603, X7
R
150F-102KAC 4
C353 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C354 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
