Integrated Circuits (continued)
Electrical Part List
Input/Output and DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
U107 KIA393F-EL/P, DUAL, VOLTAGE
COMPARATOR
3130-4990 4
U108 CODEC, CS4272-CZZ, 28PIN, TSSOP, CIRRUS
LOGIC
3132-4471 4
U109 SPI FLASH, 4M, AT45DB04, 1D-SU, SOIC8 3132-4721 4
U110 DSP, ADSP-21366KBCZ, 136-BALL CSP-BGA,
ADI
3132-4461 4
U111 BA4560F-E2, ROHM 3131-5330 4
U113 HEX INVERTER, SN74LVCU, 04APW, TSSOP,
14 PIN
3132-4731 4
U115 REGULATOR, -15V, MC7915, D2PAK, ONSEMI 3132-843111 4
U116 REGULATOR, MC7815, D2PAK, ONSEMI 3132-844111 4
U117 STEP-DOWN CONVERTER, MP1591DN,
SOIC8N, MPS
3132-4711 4
U118 REG, NCP1117ST33T3G, 3.3V, SOT-223,
ONSEMI
3132-148111 4
U119 RESET, MCP100T-315I/TT, SOT23,
MICROCHIPP
3132-4481 4
U120 STEP-DOWN CONVERTER, MP1591DN,
SOIC8N, MPS
3132-4711 4
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
CN101 2P, ST. WAFER, P=2.0, COULOMB 2102-020S 4
CN102 2P, ST. WAFER, P=2.0, COULOMB 2102-020S 4
CN301B-B WAFER, 2P, P7.92, STRAIGHT 2101-3092 4
E1B SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
E2B SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
F100 THERMAL FUSE, 40A, MAX 60V, MAX PTC,
RESETTABLE, 8X5.5
5201-5006 3, 4
F101 THERMAL FUSE, 40A, MAX 60V, MAX PTC,
RESETTABLE, 8X5.5
5201-5006 3, 4
FOR DSP COVER, SHIELD, BSPAPS2 4135-6841 4
FOR J102 BRACKET, POWER STAND, 4P, SPK SOCKET 4135-3801 4
J100 JACK, PHONE, 5P, 6.4MM, BLACK, W/SW
(BOSE
®
PART NUMBER – 741427-001S)
2113-3269
J101 JACK, PHONE, 5P, 6.4MM, BLACK 2113-3270 4
J102 SPEAKON
®
NEUTRIK
®
, 4 WIRE, NL4MD-V 2113-1336 4
J103 JACK, RJ45, ST-NE8FAV, 8 PIN, NEUTRIK 2113-3210 4
J301B 3P, ST.WAFER, P=2.0, COULOMB 2102-030S 4
J301L 3P, ST.WAFER, P=2.0, COULOMB 2102-030S 4
J302B 6 PIN WF 2102-060S 4
J302L 6 PIN WF 2102-060S 4
J303B 3P, ST.WAFER, P=2.0, COULOMB 2102-030S 4
J303L 3P, ST.WAFER, P=2.0, COULOMB 2102-030S 4
