(01) Hex Bolt 5/16”18x1 (4pcs)
(02) Lag Screw #12x1” (6pcs)
(03) Hitch Pin (3pcs)
(04) Flange Nut 1/4”-20 (4pcs)
(05) Flange Nut 5/16”-18 (4pcs)
(06) Clevis Pin Long (1pc)
(07) Clevis Pin Short (2pcs)
(08) Rope Knob (1pc)
(09) Rope (1pc)
(10) Washer(2pcs)
(11) 7W Energy Saving Bulb (1pc)
(3)
(2)
(1)
Components Identification and Inventory
Fastener (parts in screw bag) Identification
(4)
(5)
(6) (7)
(8)
(9)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(01) Power Head
(02) Header Bracket
(03) Door Bracket
(04) Door Arm: Straight
(05) Door Arm: Curved
(06) Warning Label
(07) Rail Assembly
(08) Trolley
4
(10)
(8)
(11)
