Boss BV7348B - Electric Connection; Wire Connection Diagram

-7-
ELECTRIC CONNECTION
WIRE CONNECTION
Note:
To enable the viewing of videos or photos, the Parking Brake wire must be
connected to the switched side of the parking brake when fully engaged.
Disabling the parking brake feature is strictly prohibited by law and voids
all warranties. Please review your local and state laws before attempting
to view videos or photos on the display.
RADIO ANTENNA
VIOLET/WHITE
(B+)12V
REAR CAMERA SWITCH
PARKING BRAKE(B-)
GREY
GREY/BLACK
FRONT
RCH SPK.
VIOLET
VIOLET/BLACK
WHITE
WHITE/BLACK
GREEN
GREEN/BLACK
REAR
LCH SPK.
IGNITION SWITCH(B+)
RED
REAR
RCH SPK.
FRONT
LCH SPK.
LIGHT GREEN
FUSE
FUSE
KEY GROUND(BLACK)
KEY 1(BROWN)
KEY 2(WHITE)
SUBWOOFER GREY
REAR CAMERA INPUT YELLOW
FRONT RCA AUDIO OUT
FRONT RCA AUDIO OUT
VIDEO OUTPUT
VIDEO OUTPUT
AUTO ANTENNA(+)
BLUE/WHITE
GROUND(B-)
CONSTANT(B+)
YELLOW
BLACK
White Yellow
Yellow
Red
