Boss D12F - D12 F 12 (30 cm) Flat Subwoofer; Enclosure Details

D12F 12” (30cm) Flat Subwoofer
 Single 4 Ω Voice Coil
 1000 W Peak Power Handling
 High Temperature Voice Coil
 Butyl Rubber Surround
2
5
Enclosure
The D12F is opmized for operaon in a sealed enclosure.
Since the woofer has pole-vent, it needs a minimum clearance from the
rear wall of the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality. The dimensions have already accounted
for the volume displacement of the subwoofer, using 3/4” (19mm) MDF.
All dimensions are external.
Sealed Dimensions:
Length (L) : 21” (533 mm)
Width (W) : 9” (229 mm)
Height (H) : 14” (356 mm)
Cutout Diameter: 11-1/8” (283 mm)
Int. Volume: 1.0 ³
Enclosure Dimensions
