Bpt HEC/301 - Page 12

12
XC/300
3
B
-
CP
M1
SW1
12V
HEC/301+
…KHPS (…KHPD)+
…HEP/306
(…HEP/312D)
1
CBI
CN1
HEP/306
(HEP/312D)
CN3
CN5
CBO
CN4
B IN
B OUT
B
AS/200
+B
5
21
A
16
23
B
N
M
R
C
G
4
3
2
IT/300
1.1
XT/200
A
be
ae
IN
1.5
B
SW1 SW2
2
CP
B
M1
SW1
YC/300 (YC/300A)
TL
T
bu
au
be
ae
SE 302CT01.1
IMPIANTO CITOFONICO PLURIFA-
MILIARE CON 1 INGRESSO E
INTERFACCIA TELEFONICA IT/300.
MULTI-FLAT AUDIO ENTRY INSTAL-
LATION WITH 1 ENTRANCE AND
IT/300 TELEPHONE INTERFACE.
HAUSSPRECHANLAGE FÜR MEHR-
FAMILIENHÄUSER MIT 1 AUSSEN-
STATION UND TELEFONSCHNITT-
STELLE IT/300.
INSTALLATION PORTIER ELECTRO-
NIQUE POUR IMMEUBLE AVEC 1
ENTREE ET INTERFACE TELEPHO-
NIQUE IT/300.
EQUIPO DE PORTERO ELECTRO-
NICO MULTIFAMILIAR CON 1
ENTRADA Y INTERFAZ TELEFONI-
CA IT/300.
INSTALAÇÃO TELEFONE PORTEI-
RO PLURIFAMILIAR COM 1 EN-
TRADA E INTERFACE TELEFONI-
CA IT/300.
100 m max
