Bradley BTDS76P - Original Bradley Smoker External Components List

7
(BS611, BS611EU, BS815XLT & BS815XLTCE)
External Components List
External Parts List
1. Smoke Dial Generator
2. Smoker Tower
3. Generator Supports
4. Feeder Tube
5. Smoke Generator Indicator Light
6. Bisquette Advance Button
7. Damper with handle (not shown)
8. Door
9.
10.
11.
12. Door Seal
13. Rubber Feet
14. Bisquette (not included with smoker)
